Hammond Manufacturing is a leading manufacturer of industrial and electronic enclosures, 19-inch racks and cabinets, transformers, and power distribution units with over 100 years of excellence since 1917.
Parts that are not part of a series
Company background and product focus
Hammond Manufacturing, headquartered in Guelph, Ontario, Canada, has been a leading manufacturer of enclosures and electronic packaging solutions for over 100 years since its founding in 1917. The company delivers more than 15,000 standard products to customers worldwide.
Hammond's extensive product portfolio includes:
Hammond enclosures meet NEMA, IP, UL, and CSA ratings for indoor and outdoor applications, providing protection against environmental hazards including dust, water, and corrosive atmospheres. The company's products are trusted by OEMs, systems integrators, and electrical contractors worldwide for reliable protection of sensitive electronics in demanding industrial, commercial, and telecommunications environments.
© 2026 Zenode. All rights reserved.
Product families from Hammond Manufacturing
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts from Hammond Manufacturing that are not part of a series
| Part Information | Pricing (lowest) | Transformer Type | Frequency Range (Min) | Frequency Range (Max) | Impedance - Primary (Ohms) Code | Impedance - Primary (Ohms) | DC Resistance (DCR) - Secondary | Mounting Type | DC Resistance (DCR) - Primary | Termination Style | Power Level | Frequency Response Tolerance | Size / Dimension Width | Size / Dimension Length | Height - Seated (Max) | Impedance - Secondary (Ohms) | Impedance - Secondary (Ohms) Qualifier | Turns Ratio - Primary | Turns Ratio - Secondary | Voltage - Isolation | Operating Temperature (Min) | Operating Temperature (Max) | Frequency Response | Frequency Range | Insertion Loss |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hammond Manufacturing AUDIO TRANSFORMER 100VRMS 20.4OHM PRIM. DCR 54OHM SEC. DCR 8 TERMINAL PIN THRU-HOLE | Sign in to see pricing | Miniature Epoxy Potted | 200 Hz | 100 kHz | CT | 300 Ohms | 54 Ohm | Through Hole | 20.4 Ohm | PC Pin | 100 mW | 0.5 dB | 0.45 in | 0.45 in | 0.48 in | 600 Ohms | CT | — | — | — | — | — | — | — | — |
Hammond Manufacturing AUDIO XFMR 600CT / 600CT TH | Sign in to see pricing | Miniature Epoxy Potted | 200 Hz | 100 kHz | CT | 600 Ohms | 52 Ohm | Through Hole | 44 Ohm | PC Pin | 100 mW | 0.5 dB | 0.45 in | 0.45 in | 0.48 in | 600 Ohms | CT | 1 | 1 | 100 V | -40 °C | 85 °C | — | — | — |
Hammond Manufacturing AUDIO XFMR 1.2KCT / 600CT TH | Sign in to see pricing | Miniature Epoxy Potted | 200 Hz | 100 kHz | CT | 1.2 kOhm | 53 Ohm | Through Hole | 80 Ohm | PC Pin | 100 mW | 0.5 dB | 0.45 in | 0.45 in | 0.48 in | 600 Ohms | CT | — | — | — | — | — | — | — | — |
Hammond Manufacturing AUDIO XFMR 2.5KCT / 600CT TH | Sign in to see pricing | Miniature Epoxy Potted | 200 Hz | 100 kHz | CT | 2.5 kOhm | 54 Ohm | Through Hole | 150 Ohm | PC Pin | 100 mW | 0.5 dB | 0.45 in | 0.45 in | 0.48 in | 600 Ohms | CT | — | — | — | — | — | — | — | — |
Hammond Manufacturing AUDIO XFMR 300CT / 50CT TH | Sign in to see pricing | Miniature Epoxy Potted | 200 Hz | 100 kHz | CT | 300 Ohms | 4.8 Ohm | Through Hole | 20.4 Ohm | PC Pin | 100 mW | 0.5 dB | 0.45 in | 0.45 in | 0.48 in | 50 Ohms | CT | — | — | — | — | — | — | — | — |
Hammond Manufacturing AUDIO XFMR 600CT / 50CT TH | Sign in to see pricing | Miniature Epoxy Potted | 200 Hz | 100 kHz | CT | 600 Ohms | 4.7 Ohm | Through Hole | 44 Ohm | PC Pin | 100 mW | 0.5 dB | 0.45 in | 0.45 in | 0.48 in | 50 Ohms | CT | — | — | — | — | — | — | — | — |
Hammond Manufacturing AUDIO XFMR 2.5KCT / 50CT TH | Sign in to see pricing | Miniature Epoxy Potted | 200 Hz | 100 kHz | CT | 2.5 kOhm | 4.9 Ohm | Through Hole | 150.7 Ohm | PC Pin | 100 mW | 0.5 dB | 0.45 in | 0.45 in | 0.48 in | 50 Ohms | CT | — | — | — | — | — | — | — | — |
 Hammond Manufacturing TRANSFORMER | Sign in to see pricing | General Purpose | 200 Hz | 100 kHz | — | — | 4.9 Ohm | Through Hole | 150.7 Ohm | PC Pin | 100 mW | 0.5 dB | 0.45 in | 0.45 in | 0.48 in | 50 Ohms | CT | — | — | — | — | — | — | — | — |
 Hammond Manufacturing AUDIO TRANSFORMER 100V 4OHM PRIM. DCR 95OHM SEC. DCR 5 TERMINAL PIN THRU-HOLE | Sign in to see pricing | Miniature Epoxy Potted | — | — | — | 50 Ohms | 95 Ohm | Through Hole | 4 Ohm | PC Pin | 20 mW | — | 0.57 in | 0.57 in | 0.48 in | 1.5 kOhm | — | — | — | 100 V | — | — | -1 dB | 310 Hz | 1.5 dB |
 Hammond Manufacturing AUDIO XFMR 600 / 1.5K TH | Sign in to see pricing | Miniature Epoxy Potted | — | — | — | 600 Ohms | 85 Ohm | Through Hole | 43 Ohm | PC Pin | 20 mW | — | 0.57 in | 0.57 in | 0.48 in | 1.5 kOhm | — | — | — | 100 V | — | — | -1 dB | 310 Hz | 1.5 dB |
