Product families from Aras Power Technologies
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
Parts that are not part of a series
© Zenode. All rights reserved.
Parts from Aras Power Technologies that are not part of a series
| Part Information | Pricing (lowest) | Voltage - Output 2 | Size / Dimension Height | Size / Dimension Length | Size / Dimension Width | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Isolation | Type | Voltage - Output 3 | Current - Output 3 | Current - Output 4 | Voltage - Output 1 | Voltage - Output 4 | Current - Output 1 | Number of Outputs | Applications | Features | Power (Watts) | Mounting Type | Efficiency | Approval Agency | Voltage - Input (AC) Minimum | Voltage - Input (AC) Maximum | Current - Output 2 | Standard Number | Minimum Load Required | Input Type | AC Voltage - Input (Max) | AC Voltage - Input (Min) | Current - Output (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Aras Power Technologies AC/DC CNVT 24V 12V 5V 3.3V 200W | Sign in to see pricing | 12 V | 1.57 in | 6 in | 3.5 in | 70 °C | 0 °C | 1500 Vrns | Open Frame | 5 V | 11 A | 4.5 A | 24 V | 3.3 V | 7 A | 4 | ITE (Commercial) | Universal Input | 200 W | Chassis Mount | 80 % | CB, CE | 90 V | 264 V | 2 A | 60950-1 | — | — | — | — | — |
 Aras Power Technologies AC/DC CONVERTER 15V 251W | Sign in to see pricing | — | 1.75 in | 8 in | 5 in | 50 °C | -40 °C | 1500 Vrns | Open Frame | — | — | — | 15 V | — | 16.7 A | 1 | ITE (Commercial) | PFC, Remote Sense, Standby Output, Universal Input | 250 W, 251 W | Chassis Mount | 80 % | CB, cTUVus | 85 VAC | 264 V | — | 60950-1 | No | — | — | — | — |
 Aras Power Technologies AC/DC CONVERTER 12V 200W | Sign in to see pricing | — | 1.32 in | 5 in | 3 in | 70 °C | 0 °C | 1500 Vrns | Open Frame | — | — | — | 12 V | — | 16.7 A | 1 | ITE (Commercial) | Adjustable Output, PFC, Universal Input | 200 W | Chassis Mount | 90 % | CB, cTUVus | 90 V | 264 V | — | 60950-1 | — | — | — | — | — |
 Aras Power Technologies AC/DC CONVERTER 12V 5V -12V 116W | Sign in to see pricing | 5 V | 1.4 in | 5 in | 3 in | 70 °C | 0 °C | 1500 Vrns | Open Frame | -12 V | 500 mA | — | 12 V | — | 5 A | 3 | Medical | Adjustable Output, PFC, Universal Input | 116 W | Chassis Mount | 87 % | CB, cTUVus, UL | 90 V | 264 V | 10 A | 60601-1 | — | — | — | — | — |
 Aras Power Technologies AC/DC CONVERTER 12V 150W | Sign in to see pricing | — | 1.08 in | 5 in | 3 in | 70 °C | 0 °C | 1500 Vrns | Open Frame | — | — | — | 12 V | — | 12.5 A | 1 | ITE (Commercial) | Universal Input | 150 W | Chassis Mount | 90 % | CB, CE | 90 V | 264 V | — | 60950-1 | — | — | — | — | — |
 Aras Power Technologies AC/DC CONVERTER 5V 30W | Sign in to see pricing | — | 1.04 in | 4 in | 2 in | 70 °C | 0 °C | 1500 Vrns | Open Frame | — | — | — | 5 V | — | 6 A | 1 | ITE (Commercial) | PFC, Standby Output, Universal Input | 30 W | Chassis Mount | 87 % | CB, cTUVus | 90 V | 264 V | — | 60950-1 | — | — | — | — | — |
Aras Power Technologies AC/DC CONVERTER 24V 30W | Sign in to see pricing | — | 1.04 in | 4 in | 2 in | 70 °C | 0 °C | 1500 Vrns | Open Frame | — | — | — | 24 V | — | 1.25 A | 1 | ITE (Commercial) | PFC, Standby Output, Universal Input | 30 W | Chassis Mount | 87 % | CB, cTUVus | 90 V | 264 V | — | 60950-1 | — | — | — | — | — |
 Aras Power Technologies AC/DC CONVERTER 24V 380W | Sign in to see pricing | — | 1.57 in | 5.98 in | 3.5 in | 70 °C | 0 °C | 1500 Vrns | Open Frame | — | — | — | 24 V | — | 15.8 A | 1 | Medical | Universal Input | 380 W | Chassis Mount | 90 % | CB, CE | 90 V | 264 V | — | 60601-1 | — | — | — | — | — |
 Aras Power Technologies AC/DC DIN RAIL SUPPLY 24V 240W | Sign in to see pricing | — | 4.88 in | 4.63 in | 1.89 in | 70 °C | -40 °C | 1500 Vrns | — | — | — | — | 24 V | — | — | 1 | ITE (Commercial) | PFC, Universal Input | 240 W | — | 90 % | CB, CE | — | — | — | 62368-1 | — | AC | 264 VAC | 85 VAC | 10 A |
