Analog Devices Inc./Maxim Integrated

The MAX44241/MAX44243/MAX44246 are 36V, ultra- precision, low-noise, low-drift, single/quad/dual opera- tional amplifiers that offer near-zero DC offset and drift through the use of patented chopper stabilized and auto-zeroing techniques. This method constantly mea- sures and compensates the input offset, eliminating drift over time and temperature and the effect of 1/f noise. These single/quad/dual devices feature rail-to-rail out- puts, operate from a single 2.7V to 36V supply or dual ±1.35V to ±18V supplies, and consume only 0.42mA per channel, with only 9nV/√Hz input-referred voltage noise.The ICs are available in 8-pin µMAX®or SO packages and are rated over the -40°C to +125°C temperature range.ApplicationsBattery-Powered EquipmentLoad Cell AmplifiersPLC Analog I/O ModulesPrecision InstrumentationTransducer Amplifiers

The MAX44244/MAX44245/MAX44248 family of parts provide ultra-precision, low-noise, zero-drift single/quad/ dual operational amplifiers featuring very low-power operation with a wide supply range. The devices incorporate a patented auto-zero circuit that constantly measures and compensates the input offset to eliminate drift over time and temperature as well as the effect of 1/f noise. These devices also feature integrated EMI filters to reduce high-frequency signal demodulation on the output. The op amps operate from either a single 2.7V to 36V supply or dual ±1.35V to ±18V supply. The devices are unity-gain stable with a 1MHz gain-bandwidth product and a low 90µA supply current per amplifier.The low offset and noise specifications and high supply range make the devices ideal for sensor interfaces and transmitters.The devices are available in µMAX®, SO, SOT23, and TSSOP packages and are specified over the -40°C to +125°C automotive operating temperature range.Applications4-20mA and 0 to 10V TransmittersPLC Analog I/O ModulesPortable Medical DevicesSensors InterfacesWeight Scales

The MAX44244/MAX44245/MAX44248 family of parts provide ultra-precision, low-noise, zero-drift single/quad/ dual operational amplifiers featuring very low-power operation with a wide supply range. The devices incorporate a patented auto-zero circuit that constantly measures and compensates the input offset to eliminate drift over time and temperature as well as the effect of 1/f noise. These devices also feature integrated EMI filters to reduce high-frequency signal demodulation on the output. The op amps operate from either a single 2.7V to 36V supply or dual ±1.35V to ±18V supply. The devices are unity-gain stable with a 1MHz gain-bandwidth product and a low 90µA supply current per amplifier.The low offset and noise specifications and high supply range make the devices ideal for sensor interfaces and transmitters.The devices are available in µMAX®, SO, SOT23, and TSSOP packages and are specified over the -40°C to +125°C automotive operating temperature range.Applications4-20mA and 0 to 10V TransmittersPLC Analog I/O ModulesPortable Medical DevicesSensors InterfacesWeight Scales

The MAX44241/MAX44243/MAX44246 are 36V, ultra- precision, low-noise, low-drift, single/quad/dual opera- tional amplifiers that offer near-zero DC offset and drift through the use of patented chopper stabilized and auto-zeroing techniques. This method constantly mea- sures and compensates the input offset, eliminating drift over time and temperature and the effect of 1/f noise. These single/quad/dual devices feature rail-to-rail out- puts, operate from a single 2.7V to 36V supply or dual ±1.35V to ±18V supplies, and consume only 0.42mA per channel, with only 9nV/√Hz input-referred voltage noise.The ICs are available in 8-pin µMAX®or SO packages and are rated over the -40°C to +125°C temperature range.ApplicationsBattery-Powered EquipmentLoad Cell AmplifiersPLC Analog I/O ModulesPrecision InstrumentationTransducer Amplifiers

The MAX44250/MAX44251/MAX44252 are 20V, ultra-precision, low-noise, low-drift amplifiers that offer nearzero DC offset and drift through the use of patented auto-correlating zeroing techniques. This method constantly measures and compensates the input offset, eliminating drift over time and temperature and the effect of 1/f noise. These single, dual, and quad devices feature rail-to-rail outputs, operate from a single 2.7V to 20V supply or dual ±1.35V to ±10V supplies and consume only 1.15mA per channel, while providing 5.9nV/input-referred voltage noise. The ICs are unity-gain stable with a gain-bandwidth product of 10MHz.With excellent specifications such as offset voltage of 6µV (max), drift of 19nV/°C (max), and 123nVP-Pnoise in 0.1Hz to 10Hz, the ICs are ideally suited for applications requiring ultra-low noise and DC precision such as interfacing with pressure sensors, strain gauges, precision weight scales, and medical instrumentation.The ICs are available in 5-pin SOT23, 8-pin SOT23, 8-pin µMAX®, and 14-pin SO packages and are rated over the -40°C to +125°C temperature range.ApplicationsLoad Cell and Bridge Transducer AmplificationMedical InstrumentationPrecision InstrumentationPressure TransducersStrain Gauges
