The MAX3202E/MAX3203E/MAX3204E/MAX3206E are low-capacitance ±15kV ESD-protection diode arrays designed to protect sensitive electronics attached to communication lines. Each channel consists of a pair of diodes that steer ESD current pulses to VCCor GND. The MAX3202E/MAX3203E/MAX3204E/MAX3206E protect against ESD pulses up to ±15kV Human Body Model, ±8kV Contact Discharge, and ±15kV Air-Gap Discharge, as specified in IEC 61000-4-2. These devices have a 5pF capacitance per channel, making them ideal for use on high-speed data I/O interfaces.The MAX3202E is a two-channel device intended for USB and USB 2.0 applications. The MAX3203E is a triple-ESD structure intended for USB On-the-Go (OTG) and video applications. The MAX3204E is a quad-ESD structure designed for Ethernet and FireWire® applications, and the MAX3206E is a six-channel device designed for cell phone connectors and SVGA video connections.All devices are available in tiny 4-bump (1.05mm x 1.05mm) WLP, 6-bump (1.05mm x 1.57mm) WLP, 9-bump (1.52mm x 1.52mm) WLP, 6-pin (3mm x 3mm) TDFN, and 12-pin (4mm x 4mm) TQFN packages and are specified for -40°C to +85°C operation.ApplicationsCell PhonesEthernetFireWire®SVGA Video ConnectionsUniversal Serial Bus (USB)USB 2.0Video

The MAX32001 is a fully integrated, dual channel, high performance, pin-electronics Driver/Comparator/Load (DCL) with built-in level setters and PMU force and sense switches targeting the tester market. Each channel includes a four level pin driver, window comparator, passive load, dynamic clamps, force/sense MUX switches, a high voltage (VHH) programmable level, cable-droop compensation (CDC), and 14 independent level settling DACs. The MAX32001 features programmable CDC for the driver output and for the comparator input, adjustable driver output resistance that allows optimal performance over typical data-path transmission-line variations, slew-rate adjustment, and a programmable super-voltage driver output.The MAX32001 driver features a wide 7.5V (-1.25V to +6.25V) high-speed operating voltage range and a VHH programmable range of 0V up to +13.5V. Operation modes include high-impedance, active-termination (3rd-level drive), and VHH (4th-level drive) modes. The device is highly linear even at low voltage swings. The driver provides highspeed differential control inputs compatible with most high-speed logic families. The window comparators provide extremely low timing variation over changes in slew rate, pulse width, and overdrive voltage. In high-impedance mode, the MAX32001 features dynamic clamps that dampen high-speed device-under-test (DUT) waveforms. The ±14mA passive load facilitates fast contact testing when used in conjunction with the comparators, and functions as a pullup/pulldown for open drain/collector DUT outputs. The PMU force/sense MUX switches offers force and measure current or voltage. A SPI™-compatible serial interface configures the device.The MAX32001 is available in a small footprint, 10mm x 10mm, 68-pin TQFN package with exposed pad on the top for easy heat removal. Power dissipation is 1.05W per channel typical over the full operating voltage range with the passive load disabled. The MAX32001 operates over an internal die temperature range of +50°C to +80°C.ApplicationsMemory ATE TestersSOC ATE TestersWafer Probe TestersDiscrete ATE TestersTest and Measurement Equipment

The MAX3205E/MAX3207E/MAX3208E low-capacitance, ±15kV ESD-protection diode arrays with an integrated transient voltage suppressor (TVS) clamp are suitable for high-speed and general-signal ESD protection. Low input capacitance makes these devices ideal for ESD protection of signals in HDTV, PC monitors (DVI™, HDMI®), PC peripherals (FireWire®, USB 2.0), server interconnect (PCI Express®, InfiniBand™), datacom, and interchassis interconnect. Each channel consists of a pair of diodes that steer ESD current pulses to VCCor GND.The MAX3205E/MAX3207E/MAX3208E protect against ESD pulses up to ±15kV Human Body Model, ±8kV Contact Discharge, and ±15kV Air-Gap Discharge, as specified in IEC 61000-4-2. An integrated TVS ensures that the voltage rise seen on VCCduring an ESD event is clamped to a known voltage. These devices have a 2pF input capacitance per channel, and a channel-to-channel capacitance variation of only 0.05pF, making them ideal for use on high-speed, single-ended, or differential signals.The MAX3207E is a two-channel device suitable for USB 1.1, USB 2.0 (480Mbps), and USB OTG applications. The MAX3208E is a four-channel device for Ethernet and FireWire applications. The MAX3205E is a six-channel device for cell phone connectors and SVGA video connections.The MAX3205E is available in 9-bump, tiny wafer-level package (WLP) and 16-pin, 3mm x 3mm, thin QFN packages. The MAX3207E is available in a small 6-pin SOT23 package. The MAX3208E is available in 10-pin µMAX® and 16-pin, 3mm x 3mm TQFN packages. All devices are specified for the -40°C to +125°C automotive operating temperature range.ApplicationsConsumer EquipmentDisplays/ProjectorsDVI™ Input/Output ProtectionFireWire® IEEE 1394™ PortsGraphics Controller CardsHigh-Speed Differential Signal ProtectionHigh-Speed, Full-Speed and Low-Speed USBPDAs and Cell PhonesPort ProtectionSet-Top Boxes
