Advanced Photonix provides innovative photonics and optoelectronics solutions including photodiodes, avalanche photodetectors, and custom sensors for aerospace, defense, medical, and industrial OEM applications.
Parts that are not part of a series
Company background and product focus
Advanced Photonix is a leading provider of innovative photonics, optoelectronics, and advanced electronic systems serving aerospace and defense, medical, agricultural, and industrial OEMs who demand high reliability and high-performance technology solutions. Now part of OSI Optoelectronics since 2018, Advanced Photonix continues to deliver cutting-edge sensor technology.
Advanced Photonix's optoelectronics portfolio includes:
Applications include spectroscopy, analytics, monitoring, test and measurement, communication, tracking, and imaging across aerospace, defense, medical, life sciences, industrial, and security markets.
© 2026 Zenode. All rights reserved.
Product families from Advanced Photonix
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Sensors, Transducers | 1 | Active | ||
| Optical Sensors | 1 | Active | ||
| Sensors, Transducers | 1 | Active | ||
| Optical Sensors | 1 | Active | ||
| Photodiodes | 1 | Active | ||
| Optical Sensors | 1 | Active | ||
| Optical Sensors | 1 | Active | ||
| Photodiodes | 1 | Active | ||
| Sensors, Transducers | 1 | Active | ||
| Photodiodes | 1 | Active |
Parts from Advanced Photonix that are not part of a series
| Part Information | Pricing (lowest) | Mounting Type | Operating Temperature (Max) | Operating Temperature (Min) | Wavelength (Min) | Wavelength (Max) | Package / Case | Color - Enhanced | Responsivity | Active Area Shape | Active Area Diameter | Voltage - DC Reverse (Vr) (Max) | Current - Dark (Typ) | Diode Type | Response Time | Active Area | Spectral Range (Maximum) | Spectral Range (Minimum) | Viewing Angle |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Advanced Photonix SENSOR PHOTODIOD 900-1700NM TO46 | Sign in to see pricing | Through Hole | 100 °C | -40 °C | 900 nm | 1700 nm | TO-46-2 Lens Top Metal Can | Infrared (NIR), Red | 0.83 A/W, 0.95 A/W | Dia | 0.06 mm | 35 V | 50 pA | — | — | — | — | — | — |
 Advanced Photonix SENSOR PHOTODIOD 900-1700NM TO46 | Sign in to see pricing | Through Hole | 100 °C | -40 °C | 900 nm | 1700 nm | TO-46-3 Lens Top Metal Can | Infrared (NIR), Red | 0.83 A/W, 0.95 A/W | Dia | 0.06 mm | 35 V | 50 pA | — | — | — | — | — | — |
 Advanced Photonix SENSOR PHOTODIOD 900-1700NM TO46 | Sign in to see pricing | Through Hole | 100 °C | -40 °C | 900 nm | 1700 nm | TO-46-2 Lens Top Metal Can | Infrared (NIR), Red | 0.83 A/W, 0.95 A/W | Dia | 0.1 mm | 35 V | 50 pA | — | — | — | — | — | — |
 Advanced Photonix SENSOR PHOTODIOD 900-1700NM TO46 | Sign in to see pricing | Through Hole | 100 °C | -40 °C | 900 nm | 1700 nm | TO-46-3 Lens Top Metal Can | Infrared (NIR), Red | 0.83 A/W, 0.95 A/W | Dia | 0.1 mm | 35 V | 50 pA | — | — | — | — | — | — |
 Advanced Photonix SENSOR PHOTODIOD 900-1700NM TO46 | Sign in to see pricing | Through Hole | 100 °C | -40 °C | 900 nm | 1700 nm | TO-46-3 Lens Top Metal Can | Infrared (NIR), Red | 0.83 A/W, 0.95 A/W | — | 0.25 mm | 35 V | 200 pA | — | — | — | — | — | — |
Advanced Photonix SENSOR PHOTODIODE 220-370NM TO46 | Sign in to see pricing | Through Hole | 85 °C | -40 °C | 220 nm | 370 nm | TO-46-3 Lens Top Metal Can | Ultraviolet (UV) | 0.18 A/W | — | — | 5 V | 1 pA | Schottky | 1 ns | 0.076 mm² | — | — | — |
 Advanced Photonix SENSOR PHOTODIODE 240-320NM TO46 | Sign in to see pricing | Through Hole | 85 °C | -40 °C | 240 nm | 320 nm | TO-46-3 Lens Top Metal Can | Ultraviolet (UV) | 0.1 A/W | — | — | 5 V | 1 pA | Schottky | 1 ns | 0.076 mm² | — | — | — |
Advanced Photonix SENSOR PHOTODIODE 220-280NM TO46 | Sign in to see pricing | Through Hole | 85 °C | -40 °C | 220 nm | 280 nm | TO-46-3 Lens Top Metal Can | Ultraviolet (UV) | 0.06 A/W | — | — | 5 V | 1 pA | Schottky | 1 ns | 0.076 mm² | — | — | — |
 Advanced Photonix SENSOR PHOTODIODE TO46 | Sign in to see pricing | Through Hole | 85 °C | 0 °C | — | — | — | — | 0.9 A/W | — | — | 20 V | 120 nA | — | — | — | 1700 nm | 450 nm | — |
 Advanced Photonix SENSOR PHOTODIODE 220-370NM TO46 | Sign in to see pricing | Through Hole | 125 °C | -40 °C | — | — | — | — | 0.18 A/W | — | — | 5 V | 100 nA | — | — | — | 370 nm | 220 nm | 55 ° |
