0800-3111 Series
Manufacturer: Advanced Photonix
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
SENSOR PHOTODIOD 900-1700NM TO46
| Part | Responsivity | Package / Case | Wavelength (Min) | Wavelength (Max) | Mounting Type | Voltage - DC Reverse (Vr) (Max) | Operating Temperature (Max) | Operating Temperature (Min) | Active Area Shape | Active Area Diameter | Current - Dark (Typ) | Color - Enhanced |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Advanced Photonix | 0.83 A/W 0.95 A/W | TO-46-3 Lens Top Metal Can | 900 nm | 1700 nm | Through Hole | 35 V | 100 °C | -40 °C | Dia | 1 mm | 500 pA | Infrared (NIR) Red |
