VNQ5E160 Series
Manufacturer: STMicroelectronics
Beta
⌘K
IC PWR DRVR N-CHAN 1:1 PWRSSO24
| Part | Fault Protection | Supplier Device Package | Switch Type | Interface | Current - Output (Max) [Max] | Voltage - Load [Min] | Voltage - Load [Max] | Input Type | Rds On (Typ) | Output Configuration | Ratio - Input:Output | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Supply (Vcc/Vdd) | Output Type | Mounting Type | Package / Case [y] | Package / Case | Package / Case [y] | Number of Outputs | Features | Supplied Contents | Primary Attributes [custom] | Utilized IC / Part | Type | Contents | Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 STMicroelectronics | Current Limiting (Fixed) Over Temperature Over Voltage | PowerSSO-24 | General Purpose | On/Off | 7 A | 4.5 V | 28 V | Non-Inverting | 160 mOhm | High Side | 1:1 | -40 °C | 150 °C | Not Required | N-Channel | Surface Mount | 0.295 in | 24-PowerBSOP | 7.5 mm | 4 | Auto Restart | ||||||
 STMicroelectronics | Board(s) | 4-Channel (Quad) | VNQ5E160K | Power Management | Board(s) | High Side Driver (Internal FET) |
