A14162 Series

Catalog

THERM PAD 457.2X457.2MM GRAY

Part	Color	Thermal Conductivity	Shape	Adhesive	Type	Outline [y]	Outline [x]	Thickness	Thickness	Thermal Resistivity
Laird Technologies - Thermal Materials A14162-12	Gray	1.1 W/m-K	Square	Tacky - Both Sides	Gap Filler Pad Sheet	457.2 mm	457.2 mm	2.286 mm	0.09 in
Laird Technologies - Thermal Materials A14162-02	Gray	1.1 W/m-K	Square	Tacky - Both Sides	Gap Filler Pad Sheet	457.2 mm	457.2 mm	80 mils	0.08 in	2.51 °C/W
Laird Technologies - Thermal Materials A14162-44	Gray	1.1 W/m-K	Square	Tacky - Both Sides	Gap Filler Pad Sheet	457.2 mm	457.2 mm	1.778 mm	0.07 in
Laird Technologies - Thermal Materials A14162-43	Gray	1.1 W/m-K	Square	Tacky - Both Sides	Gap Filler Pad Sheet	457.2 mm	457.2 mm	1.524 mm	0.06 in
