MCMN2012 Series

Catalog

N-CHANNEL MOSFET

Part	Drive Voltage (Max Rds On, Min Rds On)	Drain to Source Voltage (Vdss)	Gate Charge (Qg) (Max) @ Vgs [Max]	Vgs(th) (Max) @ Id	Current - Continuous Drain (Id) @ 25°C	Input Capacitance (Ciss) (Max) @ Vds	Rds On (Max) @ Id, Vgs	FET Type	Supplier Device Package	Technology	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Vgs (Max)
Micro Commercial Components MCMN2012A-TP	1.8 V 4.5 V	20 V	32 nC	1 V	12 A	1800 pF	15 mOhm	N-Channel	DFN2020-6JA	MOSFET (Metal Oxide)	Surface Mount	-55 °C	150 °C	10 V
Micro Commercial Components MCMN2012-TP	1.2 V 4.5 V	20 V	32 nC	1 V	12 A	1800 pF	11 mOhm	N-Channel	DFN2020-6J	MOSFET (Metal Oxide)	Surface Mount	-55 °C	150 °C	10 V
