ECH8308 Series

Catalog

P-CHANNEL POWER MOSFET, -12V, -10A, 12.5MOHM, SINGLE ECH8/ REEL ROHS COMPLIANT: YES

Part	Mounting Type	Rds On (Max) @ Id, Vgs [Max]	Technology	Supplier Device Package	Drive Voltage (Max Rds On, Min Rds On)	Vgs (Max)	Input Capacitance (Ciss) (Max) @ Vds [Max]	FET Type	Gate Charge (Qg) (Max) @ Vgs	Drain to Source Voltage (Vdss)	Operating Temperature	Current - Continuous Drain (Id) @ 25°C
ON Semiconductor ECH8308-TL-H	Surface Mount	12.5 mOhm	MOSFET (Metal Oxide)	8-ECH	1.8 V 4.5 V	10 V	2300 pF	P-Channel	26 nC	12 V	150 °C	10 A
ON Semiconductor ECH8308-P-TL-H	Surface Mount			8-ECH
