662-037 Series
Manufacturer: EDAC Inc.
Beta
⌘K
662 SERIES RIGHT ANGLE DUAL D-SU
| Part | Dielectric Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Connector Style | Current Rating (Amps) | Contact Finish | Backset Spacing | Backset Spacing | Contact Type | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Material Flammability Rating | Connector Type | Number of Rows [custom] | Shell Size, Connector Layout | Features | Number of Positions [Min] | Number of Positions [Max] | Flange Feature | Shell Material, Finish | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | 30 Áin | 0.76 Ám | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Board Lock Mounting Brackets Shielded | 37 | 37 | Housing/Shell (Unthreaded) | Nickel Plated Steel | ||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Mounting Brackets Shielded | 37 | 37 | Housing/Shell | Nickel Plated Steel | Flash | 4-40 | ||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | 30 Áin | 0.76 Ám | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Board Lock Mounting Brackets Shielded | 37 | 37 | Housing/Shell (M3) | Nickel Plated Steel | ||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | 30 Áin | 0.76 Ám | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Mounting Brackets Shielded | 37 | 37 | Housing/Shell | Nickel Plated Steel | 4-40 | |
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Mounting Brackets Shielded | 37 | 37 | Housing/Shell (Unthreaded) | Nickel Plated Steel | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | 30 Áin | 0.76 Ám | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Board Lock Mounting Brackets Shielded | 37 | 37 | Housing/Shell (Unthreaded) | Nickel Plated Steel | ||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | 15 µin | 0.38 µm | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Board Lock Mounting Brackets Shielded | 37 | 37 | Housing/Shell (M3) | Nickel Plated Steel | ||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | 30 Áin | 0.76 Ám | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Mounting Brackets Shielded | 37 | 37 | Housing/Shell | Nickel Plated Steel | 4-40 | |
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | 30 Áin | 0.76 Ám | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Board Lock Mounting Brackets Shielded | 37 | 37 | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | ||
 EDAC Inc. | Polyester Thermoplastic | Black | -55 C | 85 °C | Solder | D-Sub - Stacked | 3 A | Gold | 8.08 mm | 0.318 " | Signal | Right Angle Through Hole | UL94 V-0 | Receptacle Female Sockets | 2 | 4 | Mounting Brackets Shielded | 37 | 37 | 4-40 Mating Side Female Screwlock | Nickel Plated Steel | Flash |
