RZE002P02 Series
Manufacturer: Rohm Semiconductor
Beta
⌘K
MOSFETS 1.2V DRVE PCH MOSFET
| Part | Supplier Device Package | Operating Temperature | Package / Case | Vgs (Max) | Drive Voltage (Max Rds On, Min Rds On) [Max] | Drive Voltage (Max Rds On, Min Rds On) [Min] | Input Capacitance (Ciss) (Max) @ Vds [Max] | Current - Continuous Drain (Id) @ 25°C | Power Dissipation (Max) [Max] | FET Type | Vgs(th) (Max) @ Id | Technology | Gate Charge (Qg) (Max) @ Vgs | Drain to Source Voltage (Vdss) | Mounting Type | Rds On (Max) @ Id, Vgs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | EMT3 | 150 °C | SC-75 SOT-416 | 10 V | 1.2 V | 4.5 V | 115 pF | 200 mA | 150 mW | P-Channel | 1 V | MOSFET (Metal Oxide) | 1.4 nC | 20 V | Surface Mount | 1.2 Ohm |
