307-014 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 14POS 0.156
| Part | Material - Insulation | Termination Rows | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Number of Positions | Flange Feature | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Contact Material | Pitch | Pitch | Contact Type | Card Type | Number of Rows | Color | Termination | Contact Finish | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 14 | Flush Mount M3 Threaded Insert Top Opening | 14 | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Single | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Single Edge | 1 | Green | Wire Wrap | Gold | |||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 14 | Flush Mount Top Opening Unthreaded | 7 | Female | -40 C | 105 ░C | Dual | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Dual Edge | Green | Solder | Tin | 2 | 3.25 mm | 0.128 " | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 14 | 4-40 Flush Mount Threaded Insert Top Opening | 14 | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Single | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Single Edge | 1 | Green | Wire Wrap | Gold | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 14 | Flush Mount M3 Threaded Insert Top Opening | 7 | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Dual | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Dual Edge | Green | Solder | Gold | 2 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 14 | 4-40 Flush Mount Threaded Insert Top Opening | 14 | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Single | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Single Edge | 1 | Green | Solder Eyelet(s) | Gold | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 14 | 4-40 Flush Mount Threaded Insert Top Opening | 14 | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Single | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Single Edge | 1 | Green | Solder | Gold | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 14 | Flush Mount Top Opening Unthreaded | 7 | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Dual | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Dual Edge | Green | Wire Wrap | Gold | 2 | 3.96 mm | 0.156 " | 2 | |||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | 14 | Flush Mount Top Opening Unthreaded | 7 | Female | -40 C | 105 ░C | Dual | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Dual Edge | Green | Solder Eyelet(s) | Tin | 2 | 3.25 mm | 0.128 " | 2 | Card Extender | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 14 | 14 | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Single | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Single Edge | 1 | Green | Solder | Gold | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 14 | 4-40 Flush Mount Threaded Insert Top Opening | 14 | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | Single | Copper Alloy | 3.96 mm | 0.156 in | Semi Bellows | Non Specified - Single Edge | 1 | Green | Wire Wrap | Gold |
