DSC8104 Series
Manufacturer: Microchip Technology
Beta
⌘K
MEMS OSC PROG BLANK 10MHZ-460MHZ
| Part | Package / Case | Type | Programmable Type | Output | Frequency Stability | Voltage - Supply [Max] | Voltage - Supply [Min] | Available Frequency Range [Max] | Available Frequency Range [Min] | Mounting Type | Function | Current - Supply (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Base Resonator | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Ratings | Frequency Stability (Total) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Microchip Technology | 4-SMD No Lead Exposed Pad | XO (Standard) | Blank (User Must Program) | HCSL | 25 ppm | 3.6 V | 2.25 V | 460 MHz | 10 MHz | Surface Mount | Standby | 95 µA | 85 °C | -40 °C | 0.035 " | 0.9 mm | MEMS | 7 mm | 5 mm | 0.276 " | 0.197 " | ||
 Microchip Technology | 6-SMD No Lead | XO (Standard) | Blank (User Must Program) | HCSL | 3.6 V | 2.25 V | 460 MHz | 10 MHz | Surface Mount | Standby | 42 mA | 85 °C | -40 °C | 0.035 " | 0.9 mm | MEMS | 7 mm | 5 mm | 0.276 " | 0.197 " | AEC-Q100 | 10 ppm | |
 Microchip Technology | 6-SMD No Lead | XO (Standard) | Blank (User Must Program) | HCSL | 3.6 V | 2.25 V | 460 MHz | 10 MHz | Surface Mount | Standby | 42 mA | 85 °C | -40 °C | 0.035 " | 0.9 mm | MEMS | 3.2 mm | 2.5 mm | 0.126 in | 0.098 in | AEC-Q100 | 25 ppm |
