HiTemp ET Series
Thermoelectric Peltier Modules ET8,288,F2,5252,TA,R T,W6
Manufacturer: Tark Thermal Solutions
Catalog
Thermoelectric Peltier Modules ET8,288,F2,5252,TA,R T,W6
Beta
⌘K
Thermoelectric Peltier Modules ET8,288,F2,5252,TA,R T,W6
Thermoelectric Peltier Modules ET8,288,F2,5252,TA,R T,W6
Thermoelectric Peltier Modules ET8,288,F2,5252,TA,R T,W6
| Part | Type | Size / Dimension [y] | Size / Dimension [x] | Resistance | Current - Max [Max] | Operating Temperature | Features | Delta Tmax @ Th | Number of Stages | Qmax @ Th | Voltage - Max [Max] | Height [z] | Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 24.56 mm | 26.92 mm | 2.22 Ohms | 7.8 A | 150 °C | Lapped Lead Wires Sealed | 65 °C | 1 | 69 W | 16.9 V | 1.96 mm | |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 30 mm | 30 mm | 1 | 3.2 mm | ||||||||
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 30 mm | 34 mm | 1.19 Ohms | 6 A | Lapped Lead Wires Sealed | 67 °C | 1 | 29.8 W | 8.5 V | 3.81 mm | ||
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 8.94 mm | 11.38 mm | 1 | 2.44 mm | ||||||||
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | ||||||||||||
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 19.4 mm | 19.4 mm | 150 °C | Lead Wires Sealed - Silicone RTV | 77.9 °C | 1 | 7.9 W | 5.9 V | 3.58 mm | |||
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 52 mm | 56 mm | 2.57 Ohms | 15.4 A | 150 °C | Lapped Lead Wires Sealed | 67 °C | 1 | 294.6 W | 32.7 V | 3.3 mm | |
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 6.5 mm | 8.13 mm | 1 | 2.44 mm | ||||||||
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 30 mm | 30 mm | 1 | 5.59 mm | ||||||||
 Tark Thermal Solutions | TEC (Thermoelectric Cooler) | 40 mm | 40 mm | 2.88 Ohms | 6 A | 150 °C | Lapped Lead Wires Sealed | 67 °C | 1 | 53 W | 16.9 V | 3.81 mm |
