1011033 Series
Manufacturer: Integrated Power Designs
Beta
⌘K
AC/DC CONVERTER 48V 350W
| Part | Features | Current - Output 1 | Operating Temperature [Max] | Operating Temperature [Min] | Power (Watts) | Efficiency | Approval Agency | Applications | Voltage - Output 1 | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Voltage - Input [Min] | Voltage - Input [Max] | Mounting Type | Type | Number of Outputs | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Integrated Power Designs | Adjustable Output Remote Sense Universal Input | 7.3 A | 70 °C | 0 °C | 350 W | 85 % | CE cURus TUV UKCA | ITE (Commercial) Medical | 48 V | 157.5 mm | 4 " | 6.2 in | 1.75 in | 44.5 mm | 101.6 mm | 100 VAC | 240 VAC | Chassis Mount | Chassis | 1 | 60601-1; 62368-1 |
