Integrated Power Designs (IPD) is a premier US-based manufacturer of AC-DC and DC-DC power supplies, proudly made in America since 1985. Their power solutions range from 25 to 400 watts with medical and industrial certifications.
Parts that are not part of a series
Company background and product focus
Integrated Power Designs (IPD) has been a trusted name in power supply manufacturing since 1985. Based in Wilkes-Barre, Pennsylvania, IPD designs, assembles, and sells all products from their US facility, offering tariff-free, American-made power solutions for critical applications.
IPD's product portfolio includes AC-DC power supplies ranging from 25-400 watts and DC-DC converters from 70-185 watts. All units feature 1 to 4 outputs with voltages ranging from 3.3V to 48V and efficiencies up to 90%. Their power supplies carry important certifications including IEC 60601-1 for medical equipment and IEC 62368-1 for audio/video and IT equipment.
© 2026 Zenode. All rights reserved.
Product families from Integrated Power Designs
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| Series | Category | Parts | Status | Description |
|---|---|---|---|---|
| AC DC Converters | 1 | Active | ||
| Power Supplies - External/Internal (Off-Board) | 1 | Active | ||
| Power Supplies - External/Internal (Off-Board) | 1 | Active | ||
| AC DC Converters | 1 | Active | ||
| AC DC Converters | 1 | Active | ||
| Power Supplies - External/Internal (Off-Board) | 1 | Active | ||
| Power Supplies - External/Internal (Off-Board) | 1 | Active | ||
| AC DC Converters | 1 | Active | ||
| Power Supplies - External/Internal (Off-Board) | 1 | Active | ||
| AC DC Converters | 1 | Active |
Parts from Integrated Power Designs that are not part of a series
| Part Information | Pricing (lowest) | Current - Output 2 | Voltage - Output 3 | Standard Number | Type | Operating Temperature (Max) | Operating Temperature (Min) | Current - Output 1 | Current - Output 3 | Number of Outputs | Applications | Voltage - Output 1 | Voltage - Input (AC) Maximum | Voltage - Input (AC) Minimum | Features | Voltage - Output 2 | Voltage - Output 4 | Current - Output 4 | Efficiency | Size / Dimension Length | Size / Dimension Height | Size / Dimension Width | Power (Watts) | Approval Agency | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Integrated Power Designs AC/DC CONVERTER +/-5V +/-12V 65W | Sign in to see pricing | 3 A | 12 V | 62368-1 | Open Frame | 50 °C | 0 °C | 5 A | 2 A | 4 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | -5 V | -12 V | 2 A | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
Integrated Power Designs AC/DC CNVRTR 5V 2X12V -12V 65W | Sign in to see pricing | 1 A | 12 V | 62368-1 | Open Frame | 50 °C | 0 °C | 5 A | 2 A | 4 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | 12 V | -12 V | 2 A | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
 Integrated Power Designs AC/DC CNVRTR 5V 24V +/-12V 65W | Sign in to see pricing | 1 A | 12 V | 62368-1 | Open Frame | 50 °C | 0 °C | 5 A | 2 A | 4 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | 24 V | -12 V | 2 A | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
Integrated Power Designs AC/DC CONVERTER +/-5V +/-15V 65W | Sign in to see pricing | 3 A | 15 V | 62368-1 | Open Frame | 50 °C | 0 °C | 5 A | 2 A | 4 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | -5 V | -15 V | 2 A | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
Integrated Power Designs AC/DC CNVRTR 5V 24V 12V -5V 65W | Sign in to see pricing | 1 A | 12 V | 62368-1 | Open Frame | 50 °C | 0 °C | 5 A | 2 A | 4 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | 24 V | -5 V | 2 A | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
Integrated Power Designs AC/DC CNVRTR 5V 24V +/-15V 65W | Sign in to see pricing | 1 A | 15 V | 62368-1 | Open Frame | 50 °C | 0 °C | 5 A | 2 A | 4 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | 24 V | -15 V | 2 A | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
Integrated Power Designs AC/DC CONVERTER 5V +/-12V 65W | Sign in to see pricing | 3 A | 12 V | 62368-1 | Open Frame | 50 °C | 0 °C | 5 A | 1 A | 3 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | — | -12 V | — | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
Integrated Power Designs AC/DC CONVERTER 5V +/-12V 65W | Sign in to see pricing | 2 A | 12 V | 62368-1 | Open Frame | 50 °C | 0 °C | 7 A | 2 A | 3 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | — | -12 V | — | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
Integrated Power Designs AC/DC CONVERTER 5V +/-15V 65W | Sign in to see pricing | 2 A | 15 V | 62368-1 | Open Frame | 50 °C | 0 °C | 7 A | 2 A | 3 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | — | -15 V | — | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
Integrated Power Designs AC/DC CONVERTER +/-5V 12V 65W | Sign in to see pricing | 4 A | 12 V | 62368-1 | Open Frame | 50 °C | 0 °C | 5 A | 2 A | 3 | Industrial, ITE (Commercial) | 5 V | 240 VAC | 100 VAC | Adjustable Output, Universal Input | -5 V | — | — | 76 % | 6 in | 1.16 in | 4 in | 65 W | CE, TUV, UKCA | Chassis Mount |
