E1504S Series
Manufacturer: Prysmian Group
Beta
⌘K
CABLE 4COND 18AWG RED 25'
| Part | Jacket (Insulation) Thickness [x] | Jacket (Insulation) Thickness [x] | Ratings | Conductor Strand | Conductor Insulation | Jacket Color | Length [x] | Length [x] | Conductor Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Material | Cable Type | Wire Gauge | Voltage | Length | Length | Features | Number of Conductors | Usage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Prysmian Group | 0.381 mm | 0.015 in | ASTM B-3 | Solid | Poly-Vinyl Chloride (PVC) | Red | 25 ft 100 ft | 7.62 m 30.5 m | Copper Annealed Bare | 0.175 in | 4.45 mm | Poly-Vinyl Chloride (PVC) | Multi-Conductor | 18 AWG | 300 VDC | 15.24 m 304.8 m | 50 ft 1000 ft | Rip Cord | 4 | Alarm Safety |
Prysmian Group | 0.381 mm | 0.015 in | ASTM B-3 | Solid | Poly-Vinyl Chloride (PVC) | Red | Copper Annealed Bare | 0.175 in | 4.45 mm | Poly-Vinyl Chloride (PVC) | Multi-Conductor | 18 AWG | 300 VDC | 152.4 m | 500 ft | Rip Cord | 4 | Alarm Safety | ||
Prysmian Group | 0.381 mm | 0.015 in | ASTM B-3 | Solid | Poly-Vinyl Chloride (PVC) | Red | Copper Annealed Bare | 0.175 in | 4.45 mm | Poly-Vinyl Chloride (PVC) | Multi-Conductor | 18 AWG | 300 VDC | 304.8 m | 1000 ft | Rip Cord | 4 | Alarm Safety | ||
 Prysmian Group | 0.381 mm | 0.015 in | ASTM B-3 | Solid | Poly-Vinyl Chloride (PVC) | Red | Copper Annealed Bare | 0.175 in | 4.45 mm | Poly-Vinyl Chloride (PVC) | Multi-Conductor | 18 AWG | 300 VDC | 152.4 m | 500 ft | Rip Cord | 4 | Alarm Safety | ||
Prysmian Group | 0.381 mm | 0.015 in | ASTM B-3 | Solid | Poly-Vinyl Chloride (PVC) | Red | Copper Annealed Bare | 0.175 in | 4.45 mm | Poly-Vinyl Chloride (PVC) | Multi-Conductor | 18 AWG | 300 VDC | 152.4 m | 500 ft | Rip Cord | 4 | Alarm Safety | ||
Prysmian Group | 0.381 mm | 0.015 in | ASTM B-3 | Solid | Poly-Vinyl Chloride (PVC) | Red | Copper Annealed Bare | 0.175 in | 4.45 mm | Poly-Vinyl Chloride (PVC) | Multi-Conductor | 18 AWG | 300 VDC | 304.8 m | 1000 ft | Rip Cord | 4 | Alarm Safety | ||
Prysmian Group | 0.381 mm | 0.015 in | ASTM B-3 | Solid | Poly-Vinyl Chloride (PVC) | Red | 25 ft 100 ft | 7.62 m 30.5 m | Copper Annealed Bare | 0.175 in | 4.45 mm | Poly-Vinyl Chloride (PVC) | Multi-Conductor | 18 AWG | 300 VDC | 15.24 m 304.8 m | 50 ft 1000 ft | Rip Cord | 4 | Alarm Safety |
Prysmian Group | 0.381 mm | 0.015 in | ASTM B-3 | Solid | Poly-Vinyl Chloride (PVC) | Red | Copper Annealed Bare | 0.175 in | 4.45 mm | Poly-Vinyl Chloride (PVC) | Multi-Conductor | 18 AWG | 300 VDC | 152.4 m | 500 ft | Rip Cord | 4 | Alarm Safety |
