SQJ146 Series
Manufacturer: Vishay General Semiconductor - Diodes Division
Beta
⌘K
MOSFET N-CH 40V 74A PPAK SO-8
| Part | Rds On (Max) @ Id, Vgs | Mounting Type | Qualification | Drive Voltage (Max Rds On, Min Rds On) | Grade | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Gate Charge (Qg) (Max) @ Vgs [Max] | Input Capacitance (Ciss) (Max) @ Vds | Drain to Source Voltage (Vdss) | Vgs (Max) | Power Dissipation (Max) | Current - Continuous Drain (Id) @ 25°C | Supplier Device Package | FET Type | Vgs(th) (Max) @ Id [Max] | Technology | Vgs(th) (Max) @ Id |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay General Semiconductor - Diodes Division | 5.8 mOhm | Surface Mount | AEC-Q101 | 4.5 V 10 V | Automotive | PowerPAK® SO-8 | -55 °C | 175 ░C | 35 nC | 1780 pF | 40 V | 20 V | 75 W | 74 A | PowerPAK® SO-8 | N-Channel | 2.2 V | MOSFET (Metal Oxide) | |
Vishay General Semiconductor - Diodes Division | 7 mOhm | Surface Mount | AEC-Q101 | 10 V | Automotive | PowerPAK® SO-8 | -55 °C | 175 ░C | 27 nC | 1500 pF | 40 V | 20 V | 75 W | 75 A | PowerPAK® SO-8 | N-Channel | MOSFET (Metal Oxide) | 3.5 V |
