887-031 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 31POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row [custom] | Number of Positions [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Gender | Read Out | Contact Material | Color | Pitch | Pitch | Contact Finish | Card Type | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Termination | Card Thickness [Max] | Card Thickness [Min] | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | 3.25 mm | 0.128 " | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | 1 | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | 2.95 mm | 0.116 " | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Right Angle Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | 2.95 mm | 0.116 " | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Top Mount Opening |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | 3.25 mm | 0.128 " | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | 2.95 mm | 0.116 " | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 31 | 31 | 125 °C | -40 C | Cantilever | Female | Single | Copper Alloy | Black | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | Through Hole | 0.25 Ám | 10 Áin | 1 | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening |
