AME20 Series

Manufacturer: aimtec

Catalog

AC/DC CONVERTER 12V 20W

Part	Line Regulation	Load Regulation	Weight	Weight	Package / Case	Voltage - Input [Min]	Voltage - Input [Max]	Power (Watts)	Approval Agency	Applications	Number of Outputs	Mounting Type	Type	Current - Output (Max) [Max]	Voltage - Output 1	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Efficiency	Load Regulation	Line Regulation	Operating Temperature [Min]	Operating Temperature [Max]	Current - Output (Max)	Current - Output (Max)	Current - Output (Max)	Features	Weight [custom]	Weight [custom]
aimtec AME20-12SBJZ	0.5 %	±1%	160 g	0.353 lb	5-DIP Module 4 Leads	90 VAC 100 V	528 VAC 745 VDC	20 W	CE	ITE (Commercial)	1	Through Hole	Enclosed	1.66 A	12 V	70 mm	1.18 in	1.89 in	2.76 "	30 mm	48 mm
aimtec AME20-24SBJZ	0.5 %	±1%	160 g	0.353 lb	5-DIP Module 4 Leads	90 VAC 100 V	528 VAC 745 VDC	20 W	CE	ITE (Commercial)	1	Through Hole	Enclosed	833 mA	24 V	70 mm	1.18 in	1.89 in	2.76 "	30 mm	48 mm	83 %
aimtec AME20-15SBJZ	0.5 %	±1%	160 g	0.353 lb	5-DIP Module 4 Leads	90 VAC 100 V	528 VAC 745 VDC	20 W	CE	ITE (Commercial)	1	Through Hole	Enclosed	1.33 A	15 V	70 mm	1.18 in	1.89 in	2.76 "	30 mm	48 mm	83 %
aimtec AME20-5SBJZ	0.5 %	±1%	160 g	0.353 lb	5-DIP Module 4 Leads	90 VAC 100 V	528 VAC 745 VDC	18 W	CE	ITE (Commercial)	1	Through Hole	Enclosed	3.6 A	5 V	70 mm	1.18 in	1.89 in	2.76 "	30 mm	48 mm	78 %
aimtec AME20-9SBJZ			160 g	0.353 lb	5-DIP Module 4 Leads	90 VAC 100 V	528 VAC 745 VDC	20 W	CE	ITE (Commercial)	1	Through Hole	Enclosed	2.23 A	9 V	70 mm	1.18 in	1.89 in	2.76 "	30 mm	48 mm	79 %	1 %	Ý0.5%	-40 °C	70 °C
aimtec AME20-515TCJZ	0.5 %	±1%	120 g	0.265 lb	9-DIP Module 8 Leads	85 VAC 120 VDC	264 VAC 370 VDC	19 W	CE cURus	ITE (Commercial)	3	Through Hole	Enclosed		5 V	70 mm	0.93 "	1.89 in	2.76 "	23.5 mm	48 mm	76 %					300 mA	2 A	300 mA	Universal Input
aimtec AME20-524DCJZ	0.5 %	±1%	120 g	0.265 lb	9-DIP Module 7 Leads	85 VAC 120 VDC	264 VAC 370 VDC	20 W	CE cURus	ITE (Commercial)	2	Through Hole	Enclosed		5 V	70 mm	0.93 "	1.89 in	2.76 "	23.5 mm	48 mm	77 %						2.5 A 300 mA		Universal Input
aimtec AME20-15SVZ	0.5 %	±1%			8-DIP Module 5 Leads	85 VAC 100 V	264 VAC 370 VDC	20 W		ITE (Commercial)	1	Through Hole	Enclosed	1.3 A	15 V	2.44 in 62 mm				0.89 in 22.5 mm	1.77 in 45 mm				-40 °C	85 °C				Universal Input	0.209 lb	95 g
aimtec AME20-15SCJZ	0.5 %	±1%	120 g	0.265 lb	9-DIP Module 6 Leads	85 VAC 100 V	264 VAC 370 VDC	20 W	CE cURus	ITE (Commercial)	1	Through Hole	Enclosed	1.3 A	15 V	70 mm	0.93 "	1.89 in	2.76 "	23.5 mm	48 mm	83 %								Universal Input
aimtec AME20-512DCJZ	0.5 %	±1%	120 g	0.265 lb	9-DIP Module 7 Leads	85 VAC 120 VDC	264 VAC 370 VDC	20 W	CE cURus	ITE (Commercial)	2	Through Hole	Enclosed		5 V	70 mm	0.93 "	1.89 in	2.76 "	23.5 mm	48 mm	75 %						2.5 A	600 mA	Universal Input
