TMC5160 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
STEPPER MOTOR CDRIVER 8 TO 60V, FOR EXTERNAL N-FETS WITH S/D AND SPI INTERFACE, 256 ΜSTEPS, SIXPOINT RAMP CONTROLLER, COOLSTEP, STALLGUARD2, SPREADCYCLE AND STEALTHCHOP2
| Part | Motor Type - AC, DC | Output Configuration | Technology | Function | Supplier Device Package | Voltage - Supply [Max] | Voltage - Supply [Min] | Motor Type - Stepper | Step Resolution [Min] | Step Resolution [Max] | Package / Case | Current - Output | Mounting Type | Interface | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Load [Min] | Voltage - Load [Max] | Applications | Supplied Contents | Utilized IC / Part | Type | Contents | Primary Attributes | Secondary Attributes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | Universal | Half Bridge (4) | Power MOSFET | Driver - Fully Integrated Control and Power Stage | 48-TQFP-EP (7x7) | 50 V | 10 VDC | Bipolar | 1 | 0.00390625 | 48-TQFP Exposed Pad | 20 A | Surface Mount | SPI Step/Direction | -40 C | 125 °C | 10 V | 55 V | Automation Control Industrial Medical | ||||||
 Analog Devices Inc./Maxim Integrated | Board(s) | TMC5160 | Power Management | Board(s) | Motors (Stepper) | SPI Interface(s) | |||||||||||||||||||
 Analog Devices Inc./Maxim Integrated | Half Bridge (4) | BCD MOS External Power MOSFETs | Driver - Fully Integrated Control and Power Stage | 48-TQFP-EP (7x7) | 50 V | 10 VDC | Bipolar | 1 | 0.00390625 | 48-TQFP Exposed Pad | 20 A | Surface Mount | SPI Step/Direction | -40 C | 125 °C | 10 V | 55 V | Industrial | |||||||
Analog Devices Inc./Maxim Integrated | Half Bridge (4) | BCD MOS External Power MOSFETs | Driver - Fully Integrated Control and Power Stage | 48-TQFP-EP (7x7) | 50 V | 10 VDC | Bipolar | 1 | 0.00390625 | 48-TQFP Exposed Pad | 20 A | Surface Mount | SPI Step/Direction | -40 C | 125 °C | 10 V | 55 V | Industrial | |||||||
Analog Devices Inc./Maxim Integrated | Universal | Half Bridge (4) | Power MOSFET | Driver - Fully Integrated Control and Power Stage | 48-TQFP-EP (7x7) | 50 V | 10 VDC | Bipolar | 1 | 0.00390625 | 48-TQFP Exposed Pad | 20 A | Surface Mount | SPI Step/Direction | -40 C | 125 °C | 10 V | 55 V | Automation Control Industrial Medical | ||||||
 Analog Devices Inc./Maxim Integrated | Universal | Half Bridge (4) | Power MOSFET | Driver - Fully Integrated Control and Power Stage | 56-QFN (8x8) | 50 V | 10 VDC | Bipolar | 1 | 0.00390625 | 47-VFQFN Exposed Pad | 20 A | Surface Mount Wettable Flank | SPI Step/Direction | -40 C | 125 °C | 10 V | 55 V | Automation Control Industrial Medical | ||||||
 Analog Devices Inc./Maxim Integrated | Board(s) | TMC5160 | Power Management | Board(s) | Motors (Stepper) | SPI Interface(s) | |||||||||||||||||||
 Analog Devices Inc./Maxim Integrated | Board(s) | TMC5160 | Power Management | Board(s) | Motors (Stepper) | SPI Interface(s) | |||||||||||||||||||
 Analog Devices Inc./Maxim Integrated | Board(s) | TMC5160 | Power Management | Board(s) | Motors (Stepper) | SPI Interface(s) |
