MLX90614 Series

Catalog

SENSOR DGTL -40C-85C TO39

Part	Package / Case	Sensor Type	Resolution	Voltage - Supply [Min]	Voltage - Supply [Max]	Output Type	Operating Temperature [Max]	Operating Temperature [Min]	Supplier Device Package	Test Condition [Max]	Test Condition [Min]	Test Condition [Max]	Accuracy - Highest (Lowest)	Accuracy - Highest (Lowest)	Features	Sensing Temperature - Remote [Max]	Sensing Temperature - Remote [Min]	Mounting Type	Sensing Temperature - Local [Max]	Sensing Temperature - Local [Min]
Melexis Technologies NV MLX90614ESF-BCA-000-SP	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	2.6 V	3.6 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	120 °C	60 °C	4 °C	0.5 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
Melexis Technologies NV MLX90614ESF-DCI-000-SP	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	2.6 V	3.6 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	120 °C	60 °C	0.3 °C	0.2 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
Melexis Technologies NV MLX90614ESF-ACF-000-SP	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	4.5 V	5.5 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	240 °C	60 °C	4 °C	0.5 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
Melexis Technologies NV MLX90614ESF-DCI-000-TU	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	2.6 V	3.6 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	120 °C	60 °C	0.3 °C	0.2 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
Melexis Technologies NV MLX90614ESF-DAA-000-SP	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	2.6 V	3.6 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	120 °C	60 °C	0.3 °C	0.2 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
Melexis Technologies NV MLX90614ESF-BCA-000-TU	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	2.6 V	3.6 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	120 °C	60 °C	4 °C	0.5 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
Melexis Technologies NV MLX90614ESF-ABA-000-TU	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	4.5 V	5.5 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	240 °C	60 °C	4 °C	0.5 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
Melexis Technologies NV MLX90614ESF-ACC-000-TU	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	4.5 V	5.5 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	240 °C	60 °C	4 °C	0.5 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
Melexis Technologies NV MLX90614ESF-BCC-000-SP	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	2.6 V	3.6 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	120 °C	60 °C	4 °C	0.5 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
Melexis Technologies NV MLX90614ESF-BAA-000-TU	TO-39-4 Metal Can	Digital Infrared (IR)	16 b	2.6 V	3.6 V	PWM SMBus	85 °C	-40 C	TO-39	380 °C	120 °C	60 °C	4 °C	0.5 °C	Sleep Mode	380 °C	-70 °C	Through Hole	85 °C	-40 °F
