E2208S Series
Manufacturer: Prysmian Group
Beta
⌘K
CABLE 8CON 18AWG WHT SHLD 100'
| Part | Conductor Material | Number of Conductors [custom] | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Usage | Operating Temperature [Max] | Operating Temperature [Min] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Strand [custom] | Conductor Strand [custom] | Shield Coverage | Length [x] | Length [x] | Shield Type | Jacket Color | Shield Material | Jacket (Insulation) Material | Features | Cable Type | Length | Length | Wire Gauge | Voltage | Conductor Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Prysmian Group | Copper Bare | 8 | 0.203 mm | 0.008 in | Alarm Security Sound | 75 ░C | 0 °C | 0.252 in | 6.4 mm | 26 AWG | 7 | 100 % | 100 ft | 30.5 m | Foil | White | Flexfoil® | Plenum Poly-Vinyl Chloride (PVC) | Drain Wire | Multi-Conductor | 15.24 m 304.8 m | 50 ft 1000 ft | 18 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) |
Prysmian Group | Copper Bare | 8 | 0.203 mm | 0.008 in | Alarm Security Sound | 75 ░C | 0 °C | 0.252 in | 6.4 mm | 26 AWG | 7 | 25 ft 100 ft | 7.62 m 30.5 m | Foil | White | Plenum Poly-Vinyl Chloride (PVC) | Drain Wire | Multi-Conductor | 15.24 m 304.8 m | 50 ft 1000 ft | 18 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) | ||
 Prysmian Group | Copper Bare | 8 | 0.203 mm | 0.008 in | Alarm Security Sound | 75 ░C | 0 °C | 0.252 in | 6.4 mm | 26 AWG | 7 | 100 ft | 30.5 m | Foil | Natural | Plenum Poly-Vinyl Chloride (PVC) | Drain Wire | Multi-Conductor | 15.24 m 152.4 m 304.8 m | 50 ft 500 ft 1000 ft | 18 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) | ||
Prysmian Group | Copper Bare | 8 | 0.203 mm | 0.008 in | Alarm Security Sound | 75 ░C | 0 °C | 0.252 in | 6.4 mm | 26 AWG | 7 | 100 % | Foil | Natural | Flexfoil® | Plenum Poly-Vinyl Chloride (PVC) | Drain Wire | Multi-Conductor | 304.8 m | 1000 ft | 18 AWG | 300 VDC | Poly-Vinyl Chloride (PVC) |
