E3602S Series

Catalog

CABLE 2COND 18AWG WHITE SHLD

Part	Voltage	Shield Coverage	Jacket Color	Conductor Insulation	Wire Gauge	Usage	Shield Type	Number of Conductors	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Material	Conductor Strand	Cable Type	Features	Ratings	Shield Material	Jacket (Insulation) Material	Length	Length	Operating Temperature [Max]	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Length [x]	Length [x]
Prysmian Group E3602S.41.02	300 VDC	100 %	White	Poly-Vinyl Chloride (PVC)	18 AWG	Alarm Safety	Foil	2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3	Flexfoil®	Plenum Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	75 ░C	0.381 mm	0.015 in
Prysmian Group E3602S.41.03	300 VDC		Red	Poly-Vinyl Chloride (PVC)	18 AWG	Alarm Safety	Foil	2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3		Plenum Poly-Vinyl Chloride (PVC)	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft	75 ░C	0.381 mm	0.015 in	100 ft	30.5 m
Prysmian Group E3602S.41.07	300 VDC		Blue	Poly-Vinyl Chloride (PVC)	18 AWG	Alarm Safety	Foil	2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3		Plenum Poly-Vinyl Chloride (PVC)	15.24 m 76.2 m 304.8 m	50 ft 250 ft 1000 ft	75 ░C	0.381 mm	0.015 in	25 ft 100 ft	7.62 m 30.5 m
Prysmian Group E3602S.41.01	300 VDC	100 %	Black	Poly-Vinyl Chloride (PVC)	18 AWG	Alarm Safety	Foil	2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3	Flexfoil®	Plenum Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	75 ░C	0.381 mm	0.015 in
Prysmian Group E3602S.69.03	300 VDC		Red	Poly-Vinyl Chloride (PVC)	18 AWG			2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3		Plenum Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	75 ░C	0.381 mm	0.015 in
Prysmian Group E3602S.41.02	300 VDC		White	Poly-Vinyl Chloride (PVC)	18 AWG	Alarm Safety	Foil	2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3		Plenum Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	75 ░C	0.381 mm	0.015 in
Prysmian Group E3602S.41.01	300 VDC		Black	Poly-Vinyl Chloride (PVC)	18 AWG	Alarm Safety	Foil	2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3		Plenum Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	75 ░C	0.381 mm	0.015 in
Prysmian Group E3602S.41.05	300 VDC	100 %	Yellow	Poly-Vinyl Chloride (PVC)	18 AWG	Alarm Safety	Foil	2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3	Flexfoil®	Plenum Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	75 ░C	0.381 mm	0.015 in
Prysmian Group E3602S.41.07	300 VDC	100 %	Blue	Poly-Vinyl Chloride (PVC)	18 AWG	Alarm Safety	Foil	2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3	Flexfoil®	Plenum Poly-Vinyl Chloride (PVC)	304.8 m	1000 ft	75 ░C	0.381 mm	0.015 in	25 ft 100 ft	7.62 m 30.5 m
Prysmian Group E3602S.41.03	300 VDC	100 %	Red	Poly-Vinyl Chloride (PVC)	18 AWG	Alarm Safety	Foil	2	0.158 in	4.01 mm	Copper Annealed Bare	Solid	Multi-Conductor	Drain Wire Rip Cord	ASTM B-3	Flexfoil®	Plenum Poly-Vinyl Chloride (PVC)	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft	75 ░C	0.381 mm	0.015 in	100 ft	30.5 m
