TM21R Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN MOD JACK 8P8C VERT SHIELDED
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Housing Material | Contact Finish Thickness | Contact Finish Thickness | Number of Ports | Connector Type | Ratings | Orientation | LED Color | Shielding | Contact Finish | Features | Mounting Type | Termination | Contact Material | Number of Positions/Contacts | Number of Rows | Tab Direction | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | -25 °C | 80 °C | Polybutylene Terephthalate (PBT) | 50 µin | 1.27 µm | 1 | Jack | Cat5e | Vertical | Does Not Contain LED | EMI Finger Shielded | Gold | Board Lock | Through Hole | Solder | Copper Alloy | 8p8c (RJ45 Ethernet) | 1 | User Selectable | |
 Hirose Electric Co Ltd | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | Cat5e | Does Not Contain LED | EMI Finger Shielded | Through Hole | Solder | Copper Alloy | 8p8c (RJ45 Ethernet) | 1 | Up | 90 ° | ||||
Hirose Electric Co Ltd | -55 C | 85 °C | 50 µin | 1.27 µm | 4 | Jack | Cat5 | Does Not Contain LED | EMI Finger Shielded | Gold | Through Hole | Solder | Copper Alloy | 8p8c (RJ45 Ethernet) | 1 | Down | 90 ° | |||
Hirose Electric Co Ltd | -55 C | 85 °C | 50 µin | 1.27 µm | 1 | Jack | Cat5 | Does Not Contain LED | EMI Finger Shielded | Gold | Through Hole | Solder | Copper Alloy | 8p8c (RJ45 Ethernet) | 1 | Up | 90 ° | |||
 Hirose Electric Co Ltd | -25 °C | 80 °C | Polybutylene Terephthalate (PBT) | 1 | Jack | Cat5e | Does Not Contain LED | EMI Finger Shielded | Gold | Board Lock Light Pipe | Through Hole | Solder | Copper Alloy | 8p8c (RJ45 Ethernet) | 1 | Up | 90 ° | |||
 Hirose Electric Co Ltd | -25 °C | 80 °C | Polybutylene Terephthalate (PBT) | 1 | Jack | Cat5e | Does Not Contain LED | EMI Finger Shielded | Gold | Board Lock | Through Hole | Solder | Copper Alloy | 8p8c (RJ45 Ethernet) | 1 | Up | 90 ° |
