PIC32MX210F016D Series
Manufacturer: Microchip Technology
Catalog
Key Features
• * 40 MHz/66DMIPS, 32-bit RISC CPU with less than 0.5 mA/MHz current consumption
• * Two I2S/SPI modules for Codec and serial communications
• * Peripheral Pin Select (PPS) functionality
• * Parallel Master Port (PMP) for graphics interfaces
• * USB 2.0-compliant full-speed device
• * Charge Time Measurement Unit (CTMU) for mTouchTM Capacitive touch buttons and sliders
• * Temperature Range - 40°C to 105°C
• * Operating voltage range of 2.3V to 3.6V
• * Up to 32KB Flash memory (plus an additional 3 KB of Boot Flash)
• * Up to 8K SRAM memory
• * 1.56 DMIPS/MHz (Dhrystone 2.1) performance
• * MIPS32® M4K® core with MIPS16e® mode for up to 40% smaller code size
• * Pin-compatible with most Microchip 16-bit devices
• * Multiple power management modes
• * Configurable WDT with on-chip Low-Power RC oscillator for reliable operation
• * Peripheral Pin Select (PPS) functionality
• * Up to 4 channels of hardware DMA with automatic data size detection
• * Two UART and I2C™ modules
• * Separate PLLs for CPU and USB clocks
• * Hardware Real-Time Clock and Calendar (RTCC)
• * Five 16-bit Timers/Counters (two 16-bit pairs combine to create two 32-bit timers)
• * Five Capture inputs and Five Compare/PWM outputs
• * Data communication: I2S, LJ, RJ, DSP modes
• * Control interface: SPI and I2C™
• * Generation of fractional clock frequencies
• * Can be synchronized with USB clock
• * Can be tuned in run-time
• * Up to 13-channel, 10-bit ADC
• * Three Analog Comparators
• * Charge Time Measurement Unit (CTMU)
• * Two programming and debugging Interfaces
• * IEEE Standard 1149.2 compatible (JTAG) boundary scan
