807-015 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 30POS 0.156
...
| Part | Termination Rows | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Pitch | Pitch | Mounting Type | Color | Card Type | Termination | Read Out | Number of Positions | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Number of Positions/Bay/Row | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Female | 3.96 mm | 0.156 in | Through Hole | Green | Non Specified - Dual Edge | Solder | Dual | 30 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 15 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Female | 3.96 mm | 0.156 in | Through Hole | Green | Non Specified - Dual Edge | Solder | Dual | 30 | Tin | Copper Alloy | 15 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Female | 3.96 mm | 0.156 in | Right Angle Through Hole | Green | Non Specified - Dual Edge | Solder | Dual | 30 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 15 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Female | 3.96 mm | 0.156 in | Through Hole | Green | Non Specified - Dual Edge | Wire Wrap | Dual | 30 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 15 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Female | 3.96 mm | 0.156 in | Through Hole | Green | Non Specified - Single Edge | Solder | Single | 15 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 15 | 1 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Female | 3.96 mm | 0.156 in | Through Hole | Green | Non Specified - Dual Edge | Solder Eyelet(s) | Dual | 30 | Tin | Copper Alloy | 15 | |||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Female | 3.96 mm | 0.156 in | Through Hole | Green | Non Specified - Dual Edge | Solder Eyelet(s) | Dual | 30 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 15 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Female | 3.96 mm | 0.156 in | Through Hole | Green | Non Specified - Dual Edge | Solder | Dual | 30 | Gold | 0.25 Ám | 10 Áin | Copper Alloy | 15 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Female | 3.96 mm | 0.156 in | Through Hole | Green | Non Specified - Dual Edge | Solder | Dual | 30 | Tin | Copper Alloy | 15 | ||||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Female | 3.96 mm | 0.156 in | Through Hole | Green | Non Specified - Single Edge | Solder | Single | 15 | Tin | Copper Alloy | 15 | 1 |
