395-019 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 19POS 0.100
| Part | Termination Rows | Material - Insulation | Pitch | Pitch | Read Out | Features | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Gender | Contact Finish | Number of Positions/Bay/Row | Termination | Flange Feature | Number of Rows | Color | Number of Positions | Card Type | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Card Guides | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | 1 | Black | 19 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Black | 19 | Non Specified - Single Edge | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | 1 | Black | 19 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Solder | M3 Threaded Insert Top Mount Opening | 1 | Black | 19 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Card Guides | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Black | 19 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Wire Wrap | 1 | Black | 19 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.25 mm | 0.128 " | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Wire Wrap | Floating Bobbin Flush Mount | 1 | Black | 19 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2.95 mm | 0.116 " | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Wire Wrap | 1 | Black | 19 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Wire Wrap | Floating Bobbin Top Mount Opening | 1 | Black | 19 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2.95 mm | 0.116 " | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Single | Copper Alloy | -40 C | 105 ░C | Cantilever | 0.25 Ám | 10 Áin | Female | Gold | 19 | Solder | 4-40 Threaded Insert Top Mount Opening | 1 | Black | 19 | Non Specified - Single Edge | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
