UFL-2LPV Series

Catalog

CBL ASSY U.FL PLUG-PLUG 9.843"

Part	Cable Impedance	2nd Contact Gender	Operating Temperature [Max]	Operating Temperature [Min]	Cable Type	Cable Type [diameter]	2nd Connector	Length	Length	Color	Frequency - Max [Max]	1st Connector	1st Connector Mounting Type	1st Contact Gender	Style	2nd Connector Mounting Type	Overall Impedance	Length [x]	Length [x]
Hirose Electric Co Ltd UFL-2LPVHF6-04N2TV-A-250	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle	250 mm	9.843 in	Black	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)
Hirose Electric Co Ltd UFL-2LPVHF6-04N2TV-A-150	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle	150 mm	5.906 in	Black	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)
Hirose Electric Co Ltd UFL-2LPVHF6-04N1TV-A-80	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle	0.08 m	3.15 "	White	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)	50 Ohms
Hirose Electric Co Ltd UFL-2LPVHF6-04N1TV-A-70	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle			White	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)	50 Ohms	2.756 in	70 mm
Hirose Electric Co Ltd UFL-2LPVHF6-04N1TV-A-175	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle			White	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)	50 Ohms	6.89 in	175 mm
Hirose Electric Co Ltd UFL-2LPVHF6-04N2TV-A-50	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle			Black	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)		1.969 in	50 mm
Hirose Electric Co Ltd UFL-2LPVHF6-04N1TV-A-135	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle	135 mm	5.315 in	White	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)	50 Ohms
Hirose Electric Co Ltd UFL-2LPVHF6-04N2TV-A-700	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle	700 mm	27.56 in	Black	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)
Hirose Electric Co Ltd UFL-2LPVHF6-04N1TV-A-90	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle	90 mm	3.543 "	White	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)	50 Ohms
Hirose Electric Co Ltd UFL-2LPVHF6-04N2TV-A-30	50 Ohms	Female	90 °C	-40 C	Coaxial Cable	0.81 mm	U.FL (UMCC) Plug Right Angle	0.03 m	1.181 in	Black	6000 MHz	U.FL (UMCC) Plug Right Angle	Free Hanging (In-Line)	Female	U.FL (UMCC) to U.FL (UMCC)	Free Hanging (In-Line)
