E1522S Series

Catalog

CABLE 2COND 14AWG BLUE 500'

Part	Jacket (Insulation) Material	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Wire Gauge	Length	Length	Conductor Strand	Jacket Color	Conductor Material	Features	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Cable Type	Ratings	Voltage	Conductor Insulation	Length [x]	Length [x]	Usage
Prysmian Group E1522S.41.07	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	14.5 AWG	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft	Solid	Blue	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor	ASTM B-3	300 VDC	Poly-Vinyl Chloride (PVC)	100 ft	30.5 m	Alarm Safety
Prysmian Group E1522S.41.06	Poly-Vinyl Chloride (PVC) Riser	0.381 mm	0.015 in	14.5 AWG	304.8 m	1000 ft	Solid	Green	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor		300 VDC	Poly-Vinyl Chloride (PVC)			Alarm Security Sound
Prysmian Group E1522S.18.03	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	14.5 AWG	152.4 m	500 ft	Solid	Red	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor	ASTM B-3	300 VDC	Poly-Vinyl Chloride (PVC)			Alarm Safety
Prysmian Group E1522S.41.06	Poly-Vinyl Chloride (PVC) Riser	0.381 mm	0.015 in	14.5 AWG	304.8 m	1000 ft	Solid	Green	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor		300 VDC	Poly-Vinyl Chloride (PVC)			Alarm Security Sound
Prysmian Group E1522S.46.03	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	14.5 AWG			Solid	Red	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor	ASTM B-3	300 VDC	Poly-Vinyl Chloride (PVC)			Alarm Safety
Prysmian Group E1522S.41.02	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	14.5 AWG	304.8 m	1000 ft	Solid	White	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor	ASTM B-3	300 VDC	Poly-Vinyl Chloride (PVC)			Alarm Safety
Prysmian Group E1522S.41.05	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	14.5 AWG	15.24 m 304.8 m	50 ft 1000 ft	Solid	Yellow	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor	ASTM B-3	300 VDC	Poly-Vinyl Chloride (PVC)	25 ft 100 ft	7.62 m 30.5 m	Alarm Safety
Prysmian Group E1522S.38.03	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	14.5 AWG	152.4 m	500 ft	Solid	Red	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor	ASTM B-3	300 VDC	Poly-Vinyl Chloride (PVC)			Alarm Safety
Prysmian Group E1522S.41.07	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	14.5 AWG	15.24 m 152.4 m 304.8 m	50 ft 500 ft 1000 ft	Solid	Blue	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor	ASTM B-3	300 VDC	Poly-Vinyl Chloride (PVC)	100 ft	30.5 m	Alarm Safety
Prysmian Group E1522S.30.03	Poly-Vinyl Chloride (PVC)	0.381 mm	0.015 in	14.5 AWG	304.8 m	1000 ft	Solid	Red	Copper Annealed Bare	Rip Cord	5.33 mm	0.21 in	2	Multi-Conductor	ASTM B-3	300 VDC	Poly-Vinyl Chloride (PVC)			Alarm Safety
