C3523 Series
Manufacturer: Prysmian Group
Beta
⌘K
CABLE COAX PLEN RG6 18AWG 1000'
| Part | Conductor Material | Shield Material | Shield Coverage | VoP, Velocity of Propagation | Dielectric Diameter [diameter] | Dielectric Diameter [diameter] | Jacket Color | Cable Type | Jacket (Insulation) Material | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Wire Gauge | Impedance | Length [x] | Length [x] | Conductor Strand | Usage | Shield Type | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Prysmian Group | Copper Bare | Copper Flexfoil® Tinned | 95 % 100 % | 86 | 4.32 mm | 0.17 in | White | Coaxial - Plenum | Poly-Vinyl Chloride (PVC) | 5.74 mm | 0.226 in | 18 AWG | 75 Ohms | 304.8 m | 1000 ft | Solid | CATV MATV RF Signal | Braid Foil | RG-6 |
