896-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 20POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Gender | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Number of Positions/Bay/Row | Contact Type | Number of Rows [custom] | Color | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Number of Positions | Read Out | Termination Rows | Flange Feature | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 10 | Cantilever | 2 | Black | 0.156 " | 3.96 mm | Solder | 20 | Dual | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Copper Alloy | 20 Bay/Row | Cantilever | Black | 0.116 " | 2.95 mm | Solder | 20 | Single | 1 | Floating Bobbin Top Mount Opening | 1 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 10 | Cantilever | 2 | Black | 0.128 " | 3.25 mm | Wire Wrap | 20 | Dual | Side Mount Opening Unthreaded | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Copper Alloy | 20 Bay/Row | Cantilever | Black | Solder | 20 | Single | 1 | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 10 | Cantilever | 2 | Black | 0.128 " | 3.25 mm | Solder | 20 | Dual | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 10 | Cantilever | 2 | Black | 0.128 " | 3.25 mm | Wire Wrap | 20 | Dual | Side Mount Opening Unthreaded | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 10 | Cantilever | 2 | Black | Solder | 20 | Dual | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Copper Alloy | 20 Bay/Row | Cantilever | Black | Solder | 20 | Single | 1 | 4-40 Flush Mount Threaded Insert Top Opening | 1 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 2 | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Copper Alloy | 10 | Cantilever | 2 | Black | Solder | 20 | Dual | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 125 °C | -40 C | Non Specified - Single Edge | 0.25 Ám | 10 Áin | Copper Alloy | 20 Bay/Row | Cantilever | Black | 0.156 " | 3.96 mm | Wire Wrap | 20 | Single | 1 | Flush Mount Top Opening Unthreaded | 1 |
