845-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 41POS 0.100
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Contact Finish | Termination | Contact Type | Pitch | Pitch | Flange Feature | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Read Out | Color | Number of Positions | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Rows | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Solder | Cantilever | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Right Angle Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Solder | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Solder | Cantilever | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Wire Wrap | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | 0.128 " | 3.25 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Solder | Cantilever | 0.1 " | 2.54 mm | Flush Mount Top Opening Unthreaded | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | 0.156 " | 3.96 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Wire Wrap | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | 0.128 " | 3.25 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Wire Wrap | Cantilever | 0.1 " | 2.54 mm | Floating Bobbin Top Mount Opening | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | 0.116 " | 2.95 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Wire Wrap | Cantilever | 0.1 " | 2.54 mm | Side Mount Opening Unthreaded | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Solder Eyelet(s) | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 41 | Gold | Wire Wrap | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Green | 41 | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Copper Alloy | 0.156 " | 3.96 mm |
