BM61M22BFJ-C Series

Isolation Voltage 2500Vrms 1ch Gate Driver Providing Galvanic Isolation

Catalog

Isolation Voltage 2500Vrms 1ch Gate Driver Providing Galvanic Isolation

Part	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Mounting Type	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Propagation Delay tpLH / tpHL (Max)	Technology	Voltage - Output Supply [Min]	Voltage - Output Supply [Max]	Approval Agency	Operating Temperature [Max]	Operating Temperature [Min]	Common Mode Transient Immunity (Min) [Min]	Package / Case	Package / Case [y]	Package / Case [x]	Supplier Device Package	Pulse Width Distortion (Max) [Max]	Voltage - Isolation	Number of Channels [custom]
Rohm Semiconductor BM61M22BFJ-CE2	2 A	2 A	Surface Mount	15 ns	15 ns	60 ns	Capacitive Coupling	9 V	24 V	UL	125 °C	-40 °C	100 V/ns	8-SOIC	3.9 mm	0.154 in	8-SOP-J	60 ns	2500 Vrms	2

Catalog

Isolation Voltage 2500Vrms 1ch Gate Driver Providing Galvanic Isolation

Key Features

• AEC-Q100 Qualified (Grade1), Providing Galvanic Isolation, Under-voltage Lockout Function, UL1577 Recognized: File No. E356010

Description

BM61M22BFJ-C is a gate driver providing galvanic isolation with an isolation voltage of 2500Vrms, maximum I/O delay time of 60ns, and minimum input pulse width of 60ns. It incorporates the Under-voltage Lockout (UVLO) function.
