803-93 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN RCPT 44POS 0.1 GOLD SMD
| Part | Insulation Material | Contact Shape | Contact Material | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Finish - Post | Connector Type | Insulation Height | Insulation Height | Contact Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish - Mating | Mounting Type | Pitch - Mating | Pitch - Mating | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Insulation Color | Number of Positions | Material Flammability Rating | Fastening Type | Number of Rows [custom] | Number of Positions Loaded | Termination | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Contact Length - Post | Contact Length - Post | Contact Length - Post [x] | Contact Length - Post [x] | Insulation Height [z] | Insulation Height [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | 0.338 in | 8.59 mm | Female Socket | 0.76 Ám | 30 Áin | Gold | Surface Mount | 0.1 " | 2.54 mm | 4.5 A | -55 C | 125 °C | Black | 44 | UL94 V-0 | Push-Pull | 2 | All | Solder | 0.1 in | 2.54 mm | ||||||
 Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | 0.165 in | 4.2 mm | Female Socket | 0.76 Ám | 30 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | 4.5 A | -55 C | 125 °C | Black | 14 | UL94 V-0 | Push-Pull | 2 | All | Solder | 0.1 in | 2.54 mm | 0.125 in | 3.18 mm | ||||
 Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | 0.276 in | 7 mm | Female Socket | 0.76 Ám | 30 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | 4.5 A | -55 C | 125 °C | Black | 8 | UL94 V-0 | Push-Pull | 2 | All | Solder | 0.1 in | 2.54 mm | 0.118 in | 3 mm | ||||
 Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | 0.276 in | 7 mm | Female Socket | 0.76 Ám | 30 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | 4.5 A | -55 C | 125 °C | Black | 24 | UL94 V-0 | Push-Pull | 2 | All | Press-Fit Solder | 0.1 in | 2.54 mm | 0.104 in | 2.64 mm | ||||
Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | 0.338 in | 8.59 mm | Female Socket | 0.76 Ám | 30 Áin | Gold | Surface Mount | 0.1 " | 2.54 mm | 4.5 A | -55 C | 125 °C | Black | 38 | UL94 V-0 | Push-Pull | 2 | All | Solder | 0.1 in | 2.54 mm | ||||||
 Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | Female Socket | 0.76 Ám | 30 Áin | Gold | Right Angle Through Hole | 0.1 " | 2.54 mm | 4.5 A | -55 C | 125 °C | Black | 44 | UL94 V-0 | Push-Pull | 2 | All | Solder | 0.1 in | 2.54 mm | 0.126 " | 3.2 mm | 0.2 in | 5.08 mm | ||||
 Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | 0.276 in | 7 mm | Female Socket | 0.76 Ám | 30 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | 4.5 A | -55 C | 125 °C | Black | 76 | UL94 V-0 | Push-Pull | 2 | All | Solder | 0.1 in | 2.54 mm | 0.118 in | 3 mm | ||||
Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | 0.276 in | 7 mm | Female Socket | 0.76 Ám | 30 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | 4.5 A | -55 C | 125 °C | Black | 26 | UL94 V-0 | Push-Pull | 2 | All | Solder | 0.1 in | 2.54 mm | 0.118 in | 3 mm | ||||
 Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | 0.276 in | 7 mm | Female Socket | 0.76 Ám | 30 Áin | Gold | Through Hole | 4.5 A | -55 C | 125 °C | Black | 2 | UL94 V-0 | Push-Pull | 2 | All | Press-Fit Solder | 0.1 in | 2.54 mm | 0.143 in | 3.63 mm | ||||||
Mill-Max Manufacturing Corp. | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | 200 µin | 5.08 µm | Tin-Lead | Receptacle | 0.165 in | 4.2 mm | Female Socket | 0.76 Ám | 30 Áin | Gold | Through Hole | 0.1 " | 2.54 mm | 4.5 A | -55 C | 125 °C | Black | 60 | UL94 V-0 | Push-Pull | 2 | All | Solder | 0.1 in | 2.54 mm | 0.125 in | 3.18 mm |
