AM250HB Series

Manufacturer: aimtec

Catalog

DC DC CONVERTER 5V 200W

Part	Current - Output (Max) [Max]	Voltage - Input (Min) [Min]	Voltage - Isolation	Efficiency	Package / Case	Number of Outputs	Voltage - Output 1	Type	Features	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Power (Watts)	Applications	Supplier Device Package	Size / Dimension	Size / Dimension	Voltage - Input (Max) [Max]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Standard Number
aimtec AM250HB-11005SA30JZ-K-B	40 A	40 V	3000 V	88 %	Half Brick	1	5 V	Isolated Module	Adjustable Output Heatsink Remote On/Off Remote Sense	-40 C	105 ░C	Through Hole	200 Watts	Industrial Railway	Half Brick	1.25 in 2.44 " 50.8 mm	31.8 mm 58 mm 62 mm	160 V
aimtec AM250HB-11005SA30JZ	40 A	40 V	3000 V	88 %	Half Brick	1	5 V	Isolated Module	Adjustable Output Remote On/Off Remote Sense	-40 C	105 ░C	Through Hole	200 Watts	Industrial Railway	Half Brick			160 V	57.9 mm	0.54 "	13.8 mm	61 mm	2.4 in	2.28 in	50155
aimtec AM250HB-11054SA30JZ-K-B		40 V	3000 V	90 %	Half Brick	1	54 V	Isolated Module	Adjustable Output Heatsink Remote On/Off Remote Sense	-40 C	105 ░C	Through Hole	250 W	Industrial Railway	Half Brick	1.25 in 2.44 " 50.8 mm	31.8 mm 58 mm 62 mm	160 V
