000962 Series

Manufacturer: Molex

Catalog

CONN RCPT 10P 0.156 GOLD EDGE MT

Part	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating	Number of Positions Loaded	Material Flammability Rating	Current Rating (Amps)	Termination	Connector Type	Contact Finish - Post	Features	Number of Rows	Mounting Type	Pitch - Mating	Pitch - Mating	Fastening Type	Number of Positions	Insulation Color	Contact Length - Post	Contact Length - Post	Contact Finish - Mating	Contact Type	Style	Insulation Height [custom]	Insulation Height [custom]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Contact Material	Applications	Contact Shape	Insulation Height	Insulation Height
Molex 0009623101	80 °C	-40 C	600 V	All	UL94 V-2	4.5 A	Solder	Receptacle	Tin	Board Hooks	1	Board Edge Right Angle Through Hole	3.96 mm	0.156 in	Locking Ramp	10	White	3.68 mm	0.145 in	Gold	Female Socket	Board to Board Cable	0.308 "	7.82 mm	0.38 µm	15 µin	2.54 µm	100 µin	Nylon Polyamide (PA)	Brass	Automotive General Purpose Medical Telecommunications	Square
Molex 0009624039	105 ░C	-40 C	600 V	All	UL94 V-2	5 A	Solder	Receptacle	Tin	Board Hooks	1	Through Hole	3.96 mm	0.156 in	Locking Ramp		White	3.05 mm	0.12 in	Gold	Female Socket	Board to Board Cable			0.38 µm	15 µin	2.54 µm	100 µin	Nylon Polyamide (PA)	Phosphor Bronze	Automotive General Purpose Medical Telecommunications	Square	0.449 in	11.4 mm
Molex 0009623112	80 °C	-40 C	600 V	All	UL94 V-2	4 A	Solder	Receptacle Bottom Entry	Tin	Board Hooks	1	Through Hole	3.96 mm	0.156 in	Locking Ramp	11	White	4.06 mm	0.16 in	Gold	Female Socket	Board to Board Cable			0.38 µm	15 µin	2.54 µm	100 µin	Nylon Polyamide (PA)	Brass	Automotive General Purpose Medical Telecommunications	Square	0.449 in	11.4 mm
Molex 0009626065	105 ░C	-40 C	600 V	All	UL94 V-2	5 A	Solder	Receptacle	Tin	Board Hooks	1	Through Hole	3.96 mm	0.156 in	Locking Ramp	6	White	3.05 mm	0.12 in		Female Socket	Board to Board Cable			1.52 Ám	60 µin	1.52 µm	60 µin	Nylon Polyamide (PA)	Phosphor Bronze	Automotive General Purpose Medical Telecommunications	Square	0.449 in	11.4 mm
Molex 0009624028	105 ░C	-40 C	600 V	All	UL94 V-2	4.5 A	Solder	Receptacle Bottom Entry	Tin	Board Hooks	1	Through Hole	3.96 mm	0.156 in	Locking Ramp	2	White	4.06 mm	0.16 in	Gold	Female Socket	Board to Board Cable			0.38 µm	15 µin	2.54 µm	100 µin	Nylon Polyamide (PA)	Phosphor Bronze	Automotive General Purpose Medical Telecommunications	Square	0.449 in	11.4 mm
Molex 0009624057	105 ░C	-40 C	600 V	All	UL94 V-2	5 A	Solder	Receptacle	Tin	Board Hooks	1	Board Edge Right Angle Through Hole	3.96 mm	0.156 in	Locking Ramp	5	White	3.68 mm	0.145 in	Gold	Female Socket	Board to Board Cable	0.308 "	7.82 mm	0.38 µm	15 µin	2.54 µm	100 µin	Nylon Polyamide (PA)	Phosphor Bronze	Automotive General Purpose Medical Telecommunications	Square
Molex 0009623053	80 °C	-40 C	600 V	All	UL94 V-2	4.5 A	Solder	Receptacle	Tin	Board Hooks	1	Through Hole	3.96 mm	0.156 in	Locking Ramp	5	White	3.05 mm	0.12 in	Gold	Female Socket	Board to Board Cable			0.38 µm	15 µin	2.54 µm	100 µin	Nylon Polyamide (PA)	Brass	Automotive General Purpose Medical Telecommunications	Square	0.449 in	11.4 mm
Molex 0009623153	80 °C	-40 C	600 V	All	UL94 V-2	4.5 A	Solder	Receptacle	Tin	Board Hooks	1	Through Hole	3.96 mm	0.156 in	Locking Ramp	15	White	3.05 mm	0.12 in	Gold	Female Socket	Board to Board Cable			0.38 µm	15 µin	2.54 µm	100 µin	Nylon Polyamide (PA)	Brass	Automotive General Purpose Medical Telecommunications	Square	0.449 in	11.4 mm
Molex 0009626045	105 ░C	-40 C	600 V	All	UL94 V-2	5 A	Solder	Receptacle	Tin	Board Hooks	1	Through Hole	3.96 mm	0.156 in	Locking Ramp	4	White	3.05 mm	0.12 in		Female Socket	Board to Board Cable			1.52 Ám	60 µin	1.52 µm	60 µin	Nylon Polyamide (PA)	Phosphor Bronze	Automotive General Purpose Medical Telecommunications	Square	0.449 in	11.4 mm
Molex 0009626024	105 ░C	-40 C	600 V	All	UL94 V-2	4.5 A	Solder	Receptacle Bottom Entry	Tin	Board Hooks	1	Through Hole	3.96 mm	0.156 in	Locking Ramp	2	White	4.06 mm	0.16 in		Female Socket	Board to Board Cable			1.52 Ám	60 µin	1.52 µm	60 µin	Nylon Polyamide (PA)	Phosphor Bronze	Automotive General Purpose Medical Telecommunications	Square	0.449 in	11.4 mm
