Double-Balanced Mixer 8 - 16 GHz
Key Features
• Conversion Loss: 8 dB
• Noise Figure: 8 dB
• LO to RF Isolation: 44 dB
• LO to IF Isolation: 38
• RF to IF Isolation: 29 dB
• Input Third-Order Intercept: 19 dB
• Input Power for 1 dB Compression: 10 dB
• No External Components
• MSOP8GE SMT Package
Description
AI
The HMC412AMS8G & HMC412AMS8GE are passive double balanced mixers that operate between 9.0 GHz and 15 GHz. The HMC412AMS8G(E) operate with LO drive levels between +9 dBm and +13 dBm, and provides 8 dB conversion loss across the entire specified frequency band. This mixer requires no external components or bias.ApplicationsLong Haul Radio PlatformsMicrowave RadioVSAT
