LS0504 Series
Manufacturer: LITTELFUSE
Beta
⌘K
LOAD SWITCH 5V/4A 30VMAX SOT23-3/ TR ROHS COMPLIANT: YES
| Part | Current - Output | Operating Temperature [Max] | Operating Temperature [Min] | Supplier Device Package | Voltage - Input [Max] | Voltage - Input [Min] | Function | Package / Case | Mounting Type | Fault Protection | Voltage - Supply (Vcc/Vdd) | Current - Output (Max) [Max] | Voltage - Load [Max] | Voltage - Load [Min] | Number of Outputs | Rds On (Typ) | Input Type | Ratio - Input:Output | Switch Type | Features | Output Type | Interface | Output Configuration |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LITTELFUSE | 4 A | 125 °C | -40 C | SOT-23-3 | 6 V | 2.7 V | Electronic Fuse | SC-59 SOT-23-3 TO-236-3 | Surface Mount | ||||||||||||||
 LITTELFUSE | 150 °C | -40 °C | 4-DFN (1.2x1.6) | 4-UDFN | Surface Mount | Current Limiting (Adjustable) Over Temperature Over Voltage Short Circuit UVLO | Not Required | 4 A | 5.5 V | 1.8 V | 1 | 26 mOhm | Non-Inverting | 1:1 | General Purpose | Load Discharge Slew Rate Controlled | N-Channel | On/Off | High Side |
