BXRH-65 Series

Manufacturer: BRIDGELUX

Catalog

LED COB V6HD THRIVE WHT SQ 6500K

Part	Size / Dimension [y]	Size / Dimension [x]	Color	Viewing Angle	Light Emitting Surface (LES) [diameter]	CRI (Color Rendering Index)	Lumens/Watt @ Current - Test	Current - Max [Max]	Lens Type	CCT (K)	CCT (K)	Height	Type	Voltage - Forward (Vf) (Typ)	Luminous Flux @ Current/Temperature	Configuration	Temperature - Test	Current - Test
BRIDGELUX BXRH-65S1001-G-74	13.5 mm	13.5 mm	Cool White	120 °	6.6 mm	98	111 lm/W	960 mA	Flat	4-Step MacAdam Ellipse	6500 K	1.63 mm	Chip On Board (COB)	18.2 V	1414 lm	Square	25 °C
BRIDGELUX BXRH-65S0601-A-74	12.5 mm	12.5 mm	Cool White	120 °	4.5 mm 4.8 mm	98 98	107 lm/W	240 mA	Flat	4-Step MacAdam Ellipse	6500 K	1.63 mm	Chip On Board (COB)	36.4 V	682 lm	Square	25 °C	175 mA
BRIDGELUX BXRH-65S1001-B-73	13.5 mm	13.5 mm	Cool White	120 °	6.6 mm	98	111 lm/W	480 mA	Flat		6500 K	1.63 mm	Chip On Board (COB)	36.4 V	1414 lm	Square	25 °C	350 mA
BRIDGELUX BXRH-65S1001-G-73	13.5 mm	13.5 mm	Cool White	120 °	6.6 mm	98	111 lm/W	960 mA	Flat		6500 K	1.63 mm	Chip On Board (COB)	18.2 V	1414 lm	Square	25 °C
BRIDGELUX BXRH-65S1001-B-74	13.5 mm	13.5 mm	Cool White	120 °	6.6 mm	98	111 lm/W	480 mA	Flat	4-Step MacAdam Ellipse	6500 K	1.63 mm	Chip On Board (COB)	36.4 V	1414 lm	Square	25 °C	350 mA
