857-015 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 30POS 0.156
| Part | Termination Rows | Material - Insulation | Read Out | Termination | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Material | Number of Positions/Bay/Row | Contact Finish | Card Type | Gender | Number of Positions | Mounting Type | Contact Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Color | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Dual | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 15 | Tin | Non Specified - Dual Edge | Female | 30 | Right Angle Through Hole | Semi Bellows | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Dual | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 15 | Tin | Non Specified - Dual Edge | Female | 30 | Through Hole | Semi Bellows | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Dual | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 15 | Tin | Non Specified - Dual Edge | Female | 30 | Right Angle Through Hole | Semi Bellows | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 15 | Gold | Non Specified - Single Edge | Female | 15 | Through Hole | Semi Bellows | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | 1 | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 15 | Gold | Non Specified - Single Edge | Female | 15 | Through Hole | Semi Bellows | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | 1 | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Dual | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 15 | Gold | Non Specified - Dual Edge | Female | 30 | Right Angle Through Hole | Semi Bellows | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 15 | Gold | Non Specified - Single Edge | Female | 15 | Through Hole | Semi Bellows | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | 1 | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 15 | Gold | Non Specified - Single Edge | Female | 15 | Through Hole | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | 1 | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Single | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 15 | Gold | Non Specified - Single Edge | Female | 15 | Through Hole | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin | 1 | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Dual | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | 15 | Gold | Non Specified - Dual Edge | Female | 30 | Right Angle Through Hole | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Black | 125 °C | -40 C | 0.25 Ám | 10 Áin |
