KMC9BRD Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN RCPT FMALE 6P GOLD SLDR CUP
| Part | Shell Material | Connector Type | Contact Finish - Mating | Fastening Type | Color | Ingress Protection | Primary Material | Mounting Feature | Shell Finish | Number of Positions | Shell Size - Insert | Mounting Type | Orientation | Voltage Rating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insert Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Zinc Alloy | Receptacle Female Sockets | Gold | Bayonet Lock | Silver | Water Resistant | Metal | Bulkhead - Rear Side Nut | Nickel | 6 | 9 | Panel Mount | Keyed | 100 VAC 140 VDC | ||||||
 Hirose Electric Co Ltd | Zinc Alloy | Receptacle Female Sockets | Gold | Bayonet Lock | Silver | Water Resistant | Metal | Bulkhead - Rear Side Nut | Nickel | 6 | 9 | Panel Mount | Keyed | 100 VAC 140 VDC | 78.7 µin | 2 µm | Polyacetal | -10 °C | 60 °C | Phosphor Bronze |
Hirose Electric Co Ltd | Zinc Alloy | Receptacle Female Sockets | Gold | Bayonet Lock | Silver | Water Resistant | Metal | Bulkhead - Rear Side Nut | Nickel | 4 | 9 | Panel Mount | Keyed | 100 VAC 140 VDC | 78.7 µin | 2 µm | Polyacetal | -10 °C | 60 °C | Phosphor Bronze |
