DSC1103 Series

Catalog

MEMS OSC XO 147.4560MHZ LVDS SMD

Part	Frequency Stability	Type	Voltage - Supply [Max]	Voltage - Supply [Min]	Frequency	Function	Base Resonator	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Current - Supply (Disable) (Max) [Max]	Package / Case	Mounting Type	Output	Operating Temperature [Min]	Operating Temperature [Max]	Current - Supply (Max) [Max]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]
Microchip Technology DSC1103NL2-147.4560	25 ppm	XO (Standard)	3.63 V	2.25 V	147.456 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-VDFN	Surface Mount	LVDS	-40 °C	105 ░C	32 mA	7 mm	5 mm	0.276 "	0.197 "
Microchip Technology DSC1103BL2-125.0000	25 ppm	XO (Standard)	3.63 V	2.25 V	125 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-VDFN	Surface Mount	LVDS	-40 °C	105 ░C	32 mA	5 mm	3.2 mm	0.197 in	0.126 "
Microchip Technology DSC1103NI2-125.0000T	25 ppm	XO (Standard)	3.63 V	2.25 V	125 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-VDFN	Surface Mount	LVDS	-40 °C	85 °C	32 mA	7 mm	5 mm	0.276 "	0.197 "
Microchip Technology DSC1103CI2-100.0000	25 ppm	XO (Standard)	3.63 V	2.25 V	100 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-SMD No Lead 6-VDFN	Surface Mount	LVDS	-40 °C	85 °C	32 mA	3.2 mm	2.5 mm	0.126 in	0.098 in
Microchip Technology DSC1103CI1-075.0000	50 ppm	XO (Standard)	3.63 V	2.25 V	75 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-SMD No Lead 6-VDFN	Surface Mount	LVDS	-40 °C	85 °C	32 mA	3.2 mm	2.5 mm	0.126 in	0.098 in
Microchip Technology DSC1103AI2-148.5000	25 ppm	XO (Standard)	3.63 V	2.25 V	148 MHz 148.5 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-SMD No Lead Exposed Pad 6-VDFN Exposed Pad	Surface Mount	LVDS	-40 °C	85 °C	32 mA	7 mm	5 mm	0.276 "	0.197 "
Microchip Technology DSC1103DL2-156.2500	25 ppm	XO (Standard)	3.63 V	2.25 V	156.25 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-SMD No Lead 6-VDFN	Surface Mount	LVDS	-40 °C	105 ░C	32 mA	2.5 mm	2 mm	0.098 "	0.079 in
Microchip Technology DSC1103DI2-100.0000	25 ppm	XO (Standard)	3.63 V	2.25 V	100 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-SMD No Lead 6-VDFN	Surface Mount	LVDS	-40 °C	85 °C	32 mA	2.5 mm	2 mm	0.098 "	0.079 in
Microchip Technology DSC1103CI2-180.0000T	25 ppm	XO (Standard)	3.63 V	2.25 V	180 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-SMD No Lead	Surface Mount	LVDS	-40 °C	85 °C	32 mA	3.2 mm	2.5 mm	0.126 in	0.098 in
Microchip Technology DSC1103NL5-125.0000T	10 ppm	XO (Standard)	3.6 V	2.25 V	125 MHz	Standby (Power Down)	MEMS	0.035 "	0.9 mm	95 µA	6-VDFN	Surface Mount	LVDS	-40 °C	105 ░C	32 mA	7 mm	5 mm	0.276 "	0.197 "
