ATF750LVC Series

Catalog

IC CPLD 10MC 15NS 24DIP

Part	Supplier Device Package	Programmable Type	Voltage Supply - Internal [Min]	Voltage Supply - Internal [Max]	Delay Time tpd(1) Max [Max]	Number of I/O	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Package / Case	Package / Case	Package / Case	Number of Macrocells	Package / Case [custom]	Package / Case [custom]
Microchip Technology ATF750CL-15PC	24-PDIP	EE PLD	4.75 V	5.25 V	15 ns	10	70 °C	0 °C	Through Hole	0.3 in	24-DIP	7.62 mm	10
Microchip Technology ATF750C-10SC	24-SO	EE PLD	4.75 V	5.25 V	10 ns	10	70 °C	0 °C	Surface Mount		24-SOIC		10	7.5 mm	0.295 in
Microchip Technology ATF750CL-15SI	24-SO	EE PLD	4.5 V	5.5 V	15 ns	10	85 °C	-40 °C	Surface Mount		24-SOIC		10	7.5 mm	0.295 in
Microchip Technology ATF750C-7SC	24-SO	EE PLD	4.75 V	5.25 V	7.5 ns	10	70 °C	0 °C	Surface Mount		24-SOIC		10	7.5 mm	0.295 in
Microchip Technology ATF750C-15JI	28-PLCC (11.51x11.51)	EE PLD	4.5 V	5.5 V	15 ns	10	85 °C	-40 °C	Surface Mount		28-LCC (J-Lead)		10
Microchip Technology ATF750C-15PC	24-PDIP	EE PLD	4.75 V	5.25 V	15 ns	10	70 °C	0 °C	Through Hole	0.3 in	24-DIP	7.62 mm	10
Microchip Technology ATF750CL-15PU	24-PDIP	EE PLD	4.5 V	5.5 V	15 ns	10	85 °C	-40 °C	Through Hole	0.3 in	24-DIP	7.62 mm	10
Microchip Technology ATF750C-15JC	28-PLCC (11.51x11.51)	EE PLD	4.75 V	5.25 V	15 ns	10	70 °C	0 °C	Surface Mount		28-LCC (J-Lead)		10
Microchip Technology ATF750C-10PU	24-PDIP	EE PLD	4.5 V	5.5 V	10 ns	10	85 °C	-40 °C	Through Hole	0.3 in	24-DIP	7.62 mm	10
Microchip Technology ATF750C-15PI	24-PDIP	EE PLD	4.5 V	5.5 V	15 ns	10	85 °C	-40 °C	Through Hole	0.3 in	24-DIP	7.62 mm	10

Catalog

Key Features

• undefined

Description

A high-performance CMOS (electrically-erasable) complex programmable logic device (CPLD) that uses Atmel's proven electrically-erasable technology. The Microchip's "750" architecture is twice as powerful as most other 24-pin programmable logic devices. Increased product terms, sum terms, flip-flops and output logic configurations translate into more usable gates. High-speed logic and uniform, predictable delays guarantee fast in-system performance.
