JR13WR Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONNECTOR
| Part | Material Flammability Rating | Contact Finish - Mating | Applications | Color | Shell Material | Orientation | Ingress Protection | Shell Finish | Insert Material | Primary Material | Contact Material | Current Rating (Amps) | Shell Size - Insert [custom] | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shielding | Mounting Feature | Voltage Rating | Connector Type | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Fastening Type | Cable Opening | Cable Opening | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Hirose Electric Co Ltd | UL94 V-0 | Silver | Automotive Industrial Telecommunications | Black | Aluminum Alloy | Keyed | IP67/IP68 | Black Chromium | Phenol Formaldehyde (PF) | Metal | Copper Alloy | 5 A | 13 | 118.1 µin | 3 µm | Unshielded | Flange | 100 VAC 140 VDC | Receptacle Male Pins | 5 | 85 °C | -25 °C | Panel Mount | Threaded | |||
Hirose Electric Co Ltd | UL94 V-0 | Silver | Automotive Industrial Telecommunications | Black | Aluminum Alloy | Keyed | IP67/IP68 | Black Chromium | Phenol Formaldehyde (PF) | Metal | Copper Alloy | 10 A | 13 | 78.7 µin | 2 µm | Flange | 100 VAC 140 VDC | Receptacle Female Sockets | 85 °C | -25 °C | Panel Mount | Threaded | 15.9 mm | 0.626 in | |||
 Hirose Electric Co Ltd | UL94 V-0 | Silver | Automotive Industrial Telecommunications | Black | Aluminum Alloy | Keyed | IP67/IP68 | Black Chromium | Phenol Formaldehyde (PF) | Metal | Copper Alloy | 5 A | 13 | 78.7 µin | 2 µm | Flange | 100 VAC 140 VDC | Receptacle Female Sockets | 5 | 85 °C | -25 °C | Panel Mount | Threaded | 15.9 mm | 0.626 in | ||
 Hirose Electric Co Ltd | UL94 V-0 | Silver | Automotive Industrial Telecommunications | Black | Aluminum Alloy | Keyed | IP67/IP68 | Black Chromium | Phenol Formaldehyde (PF) | Metal | Copper Alloy | 5 A | 13 | 118.1 µin | 3 µm | Flange | 100 VAC 140 VDC | Receptacle Male Pins | 5 | 85 °C | -25 °C | Panel Mount | Threaded | 15.9 mm | 0.626 in | ||
Hirose Electric Co Ltd | UL94 V-0 | Silver | Automotive Industrial Telecommunications | Black | Aluminum Alloy | Keyed | IP67/IP68 | Black Chromium | Phenol Formaldehyde (PF) | Metal | Copper Alloy | 10 A | 13 | Unshielded | Flange | 250 VAC 350 VDC | Receptacle Male Pins | 85 °C | -25 °C | Panel Mount | Bayonet Lock | Solder | |||||
 Hirose Electric Co Ltd | UL94 V-0 | Silver | Automotive Industrial Telecommunications | Black | Aluminum Alloy | Keyed | IP67/IP68 | Black Chromium | Phenol Formaldehyde (PF) | Metal | Copper Alloy | 5 A | 13 | 118.1 µin | 3 µm | Flange | 100 VAC 140 VDC | Receptacle Male Pins | 5 | 85 °C | -25 °C | Panel Mount | Threaded | 15.9 mm | 0.626 in | ||
 Hirose Electric Co Ltd | UL94 V-0 | Silver | Automotive Industrial Telecommunications | Black | Aluminum Alloy | Keyed | IP67/IP68 | Black Chromium | Phenol Formaldehyde (PF) | Metal | Copper Alloy | 10 A | 13 | 78.7 µin | 2 µm | Unshielded | Flange | 100 VAC 140 VDC | Receptacle Female Sockets | 85 °C | -25 °C | Panel Mount | Threaded | ||||
Hirose Electric Co Ltd |
