PIC32CZ4010CA90208 Series
High Performance Cortex-M7 MCU 8 MB Flash/1MB SRAM and HSM
Manufacturer: Microchip Technology
Catalog
High Performance Cortex-M7 MCU 8 MB Flash/1MB SRAM and HSM
Key Features
• Processor:* Arm® Cortex®-M7
• * 300 MHz (2.14 DMIPS/MHz)
• * Instruction and Data L1 Cache 16KB each with ECC
• * Floating Point Unit (FPU)
• * Memory Protection Unit (MPU)
• * Multiply Accumulate Unit (MAC)
•
• Operating Voltage Range:* 1.75-3.6V
•
• Memory:* 4MB Dual Panel Flash with ECC
• * 1MB SRAM with ECC
• * 256KB Tightly Coupled Memory (TCM) with ECC
• * 8KB TrustRAM
•
• System:* 16-Channel DMA Controller
• * Nested Vectored Interrupt Controller (NVIC)
•
• Security:* embedded Hardware Security Module (HSM)/Secure Enclave
• * Secure Boot
• * Secure Key Storage
• * Factory Provisioning Available
•
• Safety:* Clock failure Detection
• * 32-Bit CRC
• * ECC with fault injection for Flash and SRAM
• * Programmable Supply Monitor - I/O Voltage and Core Voltage
• * Global mBIST
•
• Communications Peripherals:* 10 Serial Communication Interfaces (SERCOM), USART, I2C, SPI
• * 2 I2S modules
• * 2 SQI (Serial Quad Interface)
• * 6 CAN ports with dedicated DMA channel supporting CAN 2.0 A/Band ISO CAN-FD
• * Ethernet MAC (GMAC) 10/100/1000 Mbps in GMII, MII, and RMII. IEEE®1588 PTP and Ethernet AVB support.
• * 2 High-Speed/Full-Speed/Low-Speed USB 2.0 ports
• * Media Local Bus (MLB) Controller
• * 16-bit External Bus Interface (EBI)
• * 2-SD (HC) Memory Card Interfaces (SDHC)
•
• Analog Peripherals:* 4-core-S/H, 4.6875 Msps, 12-bit ADC SAR Module (A/D) with 36-analog channels
• * 2-Analog Comparators
• * Peripheral Capacitive Touch Controller (PTC) with 32 Self Capacitance Channels/Sensors and 16 Mutual Capacitance Channels/Sensors
•
• Timer/Counters:* 10-Timer/Counter Capture (TCC)/output compare's
• * Independent Watchdog Timer (WDT)
• * Real Time Clock (RTC)
• * Real-time Timer (RTT)
•
• Development Support:* MPLAB X IDE
• * MPLAB Harmony v3 and MCC
• * MPLAB XC32 Compiler
• * 2-wire Serial Wire Debug (SWD) Interface
• * 4-Wire JTAG Scan/Debug Interface
• * Embedded Trace Module with instruction trace stream
Description
AI
The PIC32CZ CA Family of Microcontrollers (MCUs) is a high-performance ARM® Cortex®-M7 family with up to 4MB Flash, 1 MB of SRAM, and Tightly Coupled Memory (TCM) all with ECC. Connectivity options range from standard serial communications (UART, USART, SPI, I2C, etc.,) I2S, CAN FD, and 10/100/1000 Ethernet. Advanced analog includes a 4.6875 Msps 12-Bit ADC and Peripheral Touch Controller. The PIC32CZ CA90 family variant offers an HSM with Secure Storage. Supported by MPLAB X IDE, and MPLAB® Harmony.
