GT5E Series
Manufacturer: Hirose Electric Co Ltd
Beta
⌘K
CONN COAX RCPT R/A 50 OHM PCB
| Part | Center Contact Plating | Voltage Rating | Mating Cycles | Dielectric Material | Body Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Ports | Contact Termination | Connector Type | Fastening Type | Connector Style | Center Contact Material | Frequency - Max [Max] | Features | Mounting Type | Housing Color | Impedance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Hirose Electric Co Ltd | Tin | 250 V | 30 | Polybutylene Terephthalate (PBT) | Polyamide (PA) Nylon | -30 ░C | 105 ░C | 1 | Solder | Receptacle Male Pin | Push-Pull | Coaxial | Brass | 2 GHz | Board Lock | Right Angle Through Hole | Natural | 50 Ohms |
 Hirose Electric Co Ltd | Tin | 250 V | 30 | Polybutylene Terephthalate (PBT) | Polyamide (PA) Nylon | -30 ░C | 105 ░C | 1 | Solder | Receptacle Male Pin | Push-Pull | Coaxial | Brass | 2 GHz | Board Lock | Right Angle Through Hole | Natural | 50 Ohms |
