Low Noise Amplifier SMT, 17 - 26 GHz
Key Features
• Noise Figure: 2.5 dB
• Gain: 19 dB
• OIP3: +23 dBm
• Single Supply: +3V @ 67 mA
• 50 Ohm Matched Input/Output
• RoHS Compliant 4x4 mm Package
Description
AI
The HMC517LC4 chip is a high dynamic range GaAs PHEMT MMIC Low Noise Amplifier (LNA) housed in a leadless "Pb free" RoHS compliant SMT package. The HMC517LC4 provides 19 dB of small signal gain, 2.5 dB of noise figure and has an output IP3 of +23 dBm. The P1dB output power of +13 dBm enables the LNA to also function as a LO driver for balanced, I/Q or image reject mixers. The HMC517LC4 allows the use of surface mount manufacturing techniques.ApplicationsPoint-to-Point RadiosPoint-to-Multi-Point Radios & VSATTest Equipment and SensorsMilitary
