316-93 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN SOCKET 31POS 0.1 GOLD PCB
| Part | Contact Type | Current Rating (Amps) | Contact Length - Post | Contact Length - Post | Insulation Height | Insulation Height | Contact Finish - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Number of Positions [custom] | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Color | Contact Finish - Post | Number of Rows | Contact Shape | Termination | Contact Material | Number of Positions Loaded | Connector Type | Pitch - Mating | Pitch - Mating | Material Flammability Rating | Insulation Material | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Fastening Type | Number of Positions | Insulation Height [custom] | Insulation Height [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | 0.472 " | 12 mm | Gold | -55 C | 125 °C | Through Hole | 31 | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | |||
 Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | 0.315 in | 8 mm | Gold | -55 C | 125 °C | Through Hole | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | 25 | |||
Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | 0.594 in | 15.09 mm | Gold | -55 C | 125 °C | Through Hole | 31 | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | |||
Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | 6 | 0.236 " | 6 mm | |||
Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | 0.315 in | 8 mm | Gold | -55 C | 125 °C | Through Hole | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | 10 | |||
 Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | 0.594 in | 15.09 mm | Gold | -55 C | 125 °C | Through Hole | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | 10 | |||
Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | 0.594 in | 15.09 mm | Gold | -55 C | 125 °C | Through Hole | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | 39 | |||
Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | 0.594 in | 15.09 mm | Gold | -55 C | 125 °C | Through Hole | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | 51 | |||
Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | 0.594 in | 15.09 mm | Gold | -55 C | 125 °C | Through Hole | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | 9 | |||
 Mill-Max Manufacturing Corp. | Female Socket | 3 A | 0.118 in | 3 mm | 0.315 in | 8 mm | Gold | -55 C | 125 °C | Through Hole | 0.76 Ám | 30 Áin | Black | Tin-Lead | 1 | Circular | Solder | Beryllium Copper | All | Elevated Socket | 0.1 " | 2.54 mm | UL94 V-0 | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 200 µin | 5.08 µm | Push-Pull | 53 |
